DIRECTIVES DE MONTAGE
Étape 6
Montage de la base
Grande came
DD
x 2
Grand goujon de bois
HH
Étape 7
Montage de la base
Grande came
DD
x 4
Grand goujon de bois
HH
x 2
DD
HH
HH
x 5
DD
Ajuster le panneau arrière de la base (K)
dans le sillon du panneau inférieur de la
base et glisser en place.
L
L
32
K
I
H
K
I
J
J
