TABLE OF CONTENTS

Cam Lock System Operation....................................................................................
Package Contents..................................................................................................
Hardware Contents ................................................................................................
Safety Information ..................................................................................................
Preparation...........................................................................................................
Assembly Instructions .............................................................................................
Care and Maintenance ..........................................................................................
Troubleshooting ...................................................................................................
Warranty ............................................................................................................
Replacement Parts List .........................................................................................

CAM LOCK SYSTEM OPERATION

DETAIL A
CAM BOLT
THREADED
INSERT
1. Screw cam bolt into the predrilled small holes on panel.
2. Insert cam lock into predrilled large hole on panel.
3. Make sure the arrow on the cam lock is pointed toward the cam bolt.
4. Connect both panels together, making sure cam bolt goes into predrilled hole on
the end of panel with cam lock.
5. Once cam bolt is connected inside cam lock, take Phillips screwdriver and tighten
cam lock clockwise.
CAM LOCK
PANEL
2
DETAIL B
LOCKED POSITION
PANEL
2
3
4
6
6
7
20
20
21
21
