Inflation; Inflation Option - Intex Fast-Fill 619PC Owner's Manual

INFLATION

1. Unfold the airbed. Open line cord compartment cover. See Fig (1).
2. Attach the AC line cord to the pump cord connector and plug into an AC electrical
outlet. See Fig (2 & 3).
3. Press the inflation button ( ) to inflate. See Fig (4).
4. When the airbed is inflated to the desired firmness, press " " again to switch OFF.
Note: The pump will automatically switch OFF after about five and half minutes of
operation when the pump is left unattended.
5. Lie down on the airbed to test the firmness.
6. If the sleeping surface is too hard, adjust the firmness by pressing the slight deflation
button ( ) to release some air. Press again until the desired firmness is achieved.
See Fig (5). If the airbed becomes too soft repeat step #3 thru #6 as necessary.

INFLATION OPTION

1. If electrical power is not available then a conventional foot or manually operated air
pump can be connected to the 2-in-1 valve for inflation.
2. Pull the 2-in-1 inflation valve cap out, insert air pump nozzle into the valve to inflate the
airbed. See Fig (6).
Inflate only with a low pressure inflator. Do not over inflate. Fill with cold air only.
READ AND SAVE THESE INSTRUCTIONS
(311PO) 619PC BUILT-IN ELECTRIC PUMP ENGLISH 4.875" X 7.25" 08/18/2016
FIG (2)
IMPORTANT
Page 3
FIG (1)
220 – 240 V 110 – 120 V
√
FIG (3)
FIG (4)
FIG (5)
FIG (6)
