- Page 1 1139 MC9x Smartcard Reader User Guide Technology Solutions UK Ltd Suite A, Loughborough Technology Centre, Epinal Way, Loughborough, Leicestershire, LE11 3GE, United Kingdom. Tel: +44 (0) 1509 238248 Fax: +44 (0) 1509 220020 Email: enquiries@tsl.com...
- Page 2 1139 Copyright © 2021 Technology Solutions (UK) Ltd. All rights reserved. No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without permission in writing from Technology Solutions (UK) Ltd. This includes electronic or mechanical means, such as photocopying, recording, or information storage and retrieval systems.
-
Page 3: Table Of Contents
1139 Contents Introduction ......................... 4 Parts of the 1139 Smartcard reader ................... 4 Attaching to a Mobile Computer ..................5 Detaching from a Mobile Computer ..................6 Status LEDs ........................7 USB and Charge connections .................... 8 Inserting a Smartcard ......................9 Software ........................... -
Page 4: Introduction
1139 1 Introduction Technology Solutions’ 1139 Smartcard reader is intended for use with the Motorola MC9090 and MC9190 series of Mobile Computers. It provides the Mobile Computer with the ability to read contact smartcards including the Common Access Card (CAC). The 1139 Smartcard reader is powered by the host Mobile Computer. -
Page 5: Attaching To A Mobile Computer
1139 3 Attaching to a Mobile Computer Line the latch clips on the 1139 Smartcard reader up with the slots in the side of the Mobile Computer. Push the 1139 Smartcard reader onto the Mobile computer until the latch clips click and the 1139 Smartcard reader is secured on both sides. -
Page 6: Detaching From A Mobile Computer
1139 4 Detaching from a Mobile Computer Squeeze the latch clips on each side 1139 Smartcard reader. Pull the 1139 Smartcard reader away from the Mobile Computer. Figure 3: Detaching from a Mobile Computer Technology Solutions (UK) Limited reserves the right to change its products, specifications and services at any time without notice. Page 6 of 16 www.tsl.com Copyright ©... -
Page 7: Status Leds
1139 5 Status LEDs Green Orange Figure 4: Status LEDs The 1139 Smartcard reader has two LEDs that indicate the operating status of the 1139 Smartcard reader. The Green LED lights when the driver is correctly loaded and the Mobile Computer is powered up. -
Page 8: Usb And Charge Connections
1139 6 USB and Charge connections The USB and Charge connections must only be used in areas known to be non-hazardous. Charge input USB connection Figure 5: USB and Charge connections The Charge input and USB connection are connected through the 1139 Smartcard reader directly to the Mobile Computer. -
Page 9: Inserting A Smartcard
1139 Inserting a Smartcard Figure 6: Inserting a Smartcard The Smartcard must be inserted with the contacts facing upwards, as shown in Figure 6. Push the card in until it reaches the end stop. Technology Solutions (UK) Limited reserves the right to change its products, specifications and services at any time without notice. Page 9 of 16 www.tsl.com Copyright ©... -
Page 10: Software
1139 8 Software 8.1 Driver installation The driver required for the 1139 Smartcard reader can be deployed as part of any application written for use with the 1139 Smartcard reader. If the application does not deploy the driver then it must be installed manually. To install the driver: 1. -
Page 11: Troubleshooting And Maintenance
1139 9 Troubleshooting and Maintenance 9.1 Maintenance For trouble-free service treat the 1139 Smartcard reader in the same way as you would the Mobile Computer and observe the following tips when using the 1139 Smartcard reader: Although the 1139 Smartcard reader is water and dust resistant, do not expose it to rain or moisture for an extended period of time. -
Page 12: Regulatory Information
1139 Symptoms Possible Cause Action The software application on card been Check that the card has been the Mobile Computer cannot inserted correctly. inserted fully, and that the communicate with a card gold contacts facing inserted 1139 upwards. Smartcard reader. The green LED is lit. -
Page 13: Health And Safety Recommendations
1139 11 Health and Safety Recommendations Ergonomic Recommendations Caution: In order to avoid or minimize the potential risk of ergonomic injury, follow the recommendations below. Consult with your local Health & Safety Manager to ensure that you are adhering to your company's safety programs to prevent employee injury. Reduce or eliminate repetitive motion Maintain a natural position Reduce or eliminate excessive force... -
Page 14: Waste Electrical And Electronic Equipment (Weee)
1139 12 Waste Electrical and Electronic Equipment (WEEE) For EU Customers: All products at the end of their life must be returned to TSL for recycling. For information on how to return product please contact TSL. 13 Warranty (A) Warranty TSL’s hardware Products are warranted against defects in workmanship and materials for a period of twelve (12) months from the date of shipment, unless otherwise provided by TSL in writing, provided the Product remains unmodified and is operated under... - Page 15 1139 parameters set forth in the applicable Product specification; nor shall the above warranty provisions apply to any expendable or consumable items, such as batteries, supplied with the Product. EXCEPT FOR THE WARRANTY OF TITLE AND THE EXPRESS WARRANTIES STATED ABOVE, TSL DISCLAIMS ALL WARRANTIES ON PRODUCTS FURNISHED HEREUNDER INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE.
