zBoost
SOHO
®
YX550
4G AWS/VLTE User Guide
zBoost products have a 30-day money back guarantee when purchased directly from
Wi-Ex®. If product is purchased from a reseller or third party, the purchaser is subject to the
policies of the third party.
1 Year Manufacturer Warranty. Register at www.Wi-Ex.com
v.062512
