UNILITE FL-4R User Manual

FEATURES
• Super bright 450 Lumen white CREE LED
• Hard anodized die cast matte aluminium body
• Tactical rubberised micro switch
• 3 Light modes & 8Hz defence strobe
• Flawless smooth reflector for long range beam
• Dust and waterproof IP67 - 1m submersible
• Impact resistant to 1m
• Nylon Velcro holster & safety wrist strap (inc)
• High quality 3.7v 800 mAh 14500 Li-ion Battery (inc)
• Built-in USB charge port with protective rubber cover
• Now USB Type-C charging - 2 hour charge time
BATTERY - 3.7v 800mAh 14500 Li-ion Rechargeable Battery
WEIGHT - 109g (including battery)
DIMENSIONS - Ø30mm x 113mm
ADVICE & IMPORTANT INFORMATION!
• Do not look directly at the LED. Do not operate in direct sunlight or extreme
temperature conditions (below -10°C or above 40°C).
• LEDs will become warm/hot when switched on; do not touch and never place LEDs
face down on any surface – risk of fire!
• The aluminium housing can get warm. If it gets too hot, turn down the brightness or
turn off and allow to cool.
• Do not use the product in the immediate vicinity of flammable materials or gases.
• Do not use the device if there is any visible damage to the housing, charge port,
switch or cable. Take care when using a USB plug adaptor, check for any damage.
• DO NOT exceed 5V 1A charging input or damage may occur to the battery.
• Make sure the charge port cover is securely closed after charging.
• This product is water proof to IPX7 – 1m SUBMERSIBLE. Do not submerge any
deeper than 1m as the water pressure can cause water to ingress. If the product has
been affected by deep water, remove the battery and leave the unit open and allow
to dry out completely before using. If the product has been subjected to deep water
the warranty may be void.
• The rechargeable battery will reach full performance after a few complete charging
and discharging cycles. To keep the rechargeable battery in optimum condition, it
should be recharged every 3-6 months, especially if it is not being used for long
periods of time.
• Always fully charge batteries before storage. Remember to remove the rechargeable
battery before storage to avoid battery depletion.
• ONLY USE HIGH-QUALITY 14500 LI-ION
PROTECTION OTHERWISE DAMAGE MAY OCCUR TO THE FLASHLIGHT.
www.unilite.co.uk
BATTERIES WITH OVER CHARGE
ANSI F L 1 Standard
HIGH
MEDIUM
LOW
8Hz STROBE
OPERATION
SWITCH Sequence: High > Medium > Low > 8Hz Flashing > Off
[If left in any mode for 10 seconds, next press will turn off]
CHARGING
1. Only use a 5V 1A USB-C charging cable.
2. Switch product off before charging.
3. Lift the charging port cover on the side of the flashlight.
4. Plug the USB-C end of the cable into the charge port.
5. Plug the USB end of the cable into a USB charging port (do not
exceed 5V 1A charging input or damage may occur).
6. The LED indicator will light up RED to indicate charging. Once
fully charged it will turn GREEN.
7. Charge Time: 2 hours
8. Remove charging cable and make sure the charge port cover is
securely closed to avoid water ingress.
Fully charge before first use.
**Warranty void if not used with the specified charger**
FL-4R
Charge
Port
Cover
1 x 3.7V 800mAh 14500 Li-ion
Rechargeable Battery
NOTE: Must use Unilite battery
OPEN
• Always protect batteries from heat, intense sunlight, fire, water and moisture –
danger of explosion!
• If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin
irritation and/or burns. If skin contact occurs, rinse thoroughly with water. If irritation
persists, seek medical advice. Seek immediate medical assistance if lithium battery
fluid comes into contact with the eyes.
• If the battery is installed and the flashlight does not work, try checking for the
following: (1) Press the switch several times. (2) Check that the battery is inserted the
correct way around according to polarity markings. (3) Check there is no debris on
the contacts that might affect the battery connection. (4) Check there is no water or
dampness in the flashlight, if so, allow it to fully dry out and try again.
• Children under 12 years of age should only use the product under adult supervision.
• Do not disassemble or attempt to modify the product; this will void the warranty and
can be dangerous. Improper use or modification is not covered under the warranty.
• Take care not to let lenses come into contact with hard/sharp objects, damage/
scratches to lenses can affect light output.
• This product has a 1 year standard warranty (or extended 2 years once registered
online at WWW.UNILITE.CO.UK/WARRANTY) against manufacturing faults and
defects. It does not cover normal wear and tear, modifications, accidental damage
or poor maintenance. Unilite warranties do not cover battery leaks or the use of
incorrect chargers and cables that can damage rechargeable batteries.
• Do not dispose of this device in normal household waste. It must be disposed of via
an authorised electrical appliance disposal centre or at your local waste disposal unit.
• Please re-use or recycle packaging where possible.
• Keep these instructions for future reference or for subsequent possessors.
FL-4R
450
210 M 2 H
Lumens
160
125 M 5
Lumens
20
20 H
40 M
Lumens
-- 3
--
OPEN
USB-C Cable – To PC /
USB Battery Charger / Power Bank etc
Battery Power Indicator
Red LED on = Medium Battery
Red LED Flashing = Low Battery
Charging Status Indicator
Red LED on = Charging
Green LED on = Fully Charged
