UNILITE FL-4R Quick Start Manual

FL-4R - USB RECHARGEABLE ALUMINIUM FLASHLIGHT
FEATURES
• White Cree LED - Up to 450 Lumens
• Built in USB Rubberised Charging Point
• Hard Anodized Die Cast Matte Aluminium Body
• Tactical Rubberised Micro Switch Operation
• 3 Light Mode Settings & 8Hz Defence Strobe
• Flawless Smooth Reflector for Long Distance Beam
• Battery Indicator Shows Capacity & Charging Status
• Circuit Protection Prevents Battery from Over-charging
or Over-discharging
• Rock-solid Protection - 1m Drop-proof, IP6X Dust-proof
& IPX7 Waterproof (1m submersible)
SPECIFICATIONS
Colour Matte Black
Operation HIGH > MED > LOW > 8Hz FLASHING > OFF
[If left in any mode for 10 seconds, next press will turn off]
Battery Type 1 x 3.7V 800mAh 14500 Li-ion Rechargeable Battery
[Included]
Charging Info 2hrs Charging Time [DC5V 1000mA input]
Red LED ON - Charging / Green LED ON - Fully Charged
Battery Cycle 500 Cycles (Reserves ~80% Capacity after 500 cycles)
Bulb Type 1 x Cree White LED
Accessories Micro USB charging Cable, Nylon Velcro Carrying Pouch
with Carabiner & Safety Wrist Strap
Size Ø30mm x 113mm
Weight 109g [with battery]
ANSI FL 1
450
Lumens
160
Lumens
20
Lumens
NA
ADVICE & IMPORTANT INFORMATION!
Do not look directly at the LED. Do not operate in direct sunlight or extreme temperature conditions (below -10⁰C or above 40⁰C). The LED will become hot when switched
on; do not touch and do not place face down on any surface – risk of fire!
Do not use the device if there is any visible damage to the housing, plug or cable. Children under 12 years of age should only use the product under adult supervision.
Do not open, disassemble or attempt to modify the product; this will void the warranty and can be dangerous. Improper use or modification is not covered under the
warranty.
Ensure the lens does come into contact with hard/sharp objects; damage to the lens may affect light output.
To maintain the rechargeable batteries, distributors should recharge the battery every 6 months and users should recharge every 3 months if not using for an extended
period. Fully charge the product before storage. The rechargeable batteries will reach their optimum performance only after several complete charging and discharging
cycles. Protect the battery from heat, intense sunlight, fire, water and moisture – danger of explosion!
If the battery is damaged, fluids can leak out. AVOID contact as this can lead to skin irritation and/or burns. If skin contact happens, rinse thoroughly with water. If irritation
persists, seek medical advice. Also seek immediate medical assistance if battery fluid comes into contact with the eyes.
Do not dispose of this device in normal household waste. It must be disposed of via an authorised disposal centre or at your local waste disposal unit. Please recycle
packaging where possible. Keep these instructions for future reference or for subsequent possessors.
Unilite Limited - The LAB, Winyates Way, Moons Moat North Ind. Est., Redditch, Worcestershire, B98 9FG - UK
T • 00[44] 1527 584 344 F • 00[44] 1527 584 345
210m 2h
125m 5h30min
40m 20h
NA 3h30min
E • sales@unilite.co.uk
Charge OPEN
Jack
Cover
W • www.unilite.co.uk
1 x 3.7V 800mAh 14500 Li-ion
Rechargeable Battery
NOTE: Must use Unilite battery
Micro USB Cable – To PC /
USB Battery Charger / Power Bank etc
Battery Power Indicator
Red LED on = Medium Battery
Red LED Flashing = Low Battery
Charging Status Indicator
Red LED on = Charging
Green LED on = Fully Charged
OPEN
