12 en | Wiring and Addressing Information
Terminal Lettering
SC
S
S
in
S
out
C
Figure 5.1 FAA-440-B6/-B4 Standard Base Class B Wiring (Class A Wiring Indicated by Dashed Wire)
+ +
Figure 5.2 FAA-440-B6-ISO/-B4-ISO Isolator Base Class B Wiring (Class A Wiring Indicated by Dashed Wire)
F.01U.173.498 | 1.3 | 2012.02
Terminal Function
SLC bus - IN/OUT
SLC bus + IN/OUT
SLC bus + IN
SLC bus + OUT
Remote output
SC
S
+
+
SC
Sin
+
+
Installation and Operation Guide
S
SC
SC
S
Sout -> Sin
SC
SC
Sout
Analog Detectors and Bases
S
SC
Sout
SC
