- Page 1 Robotic UV Vacuum Cleaner & Mop Model No. : RVC-1409-HC Quick Guide...
-
Page 2: Overview Of Machine
English Parts Identifications Main machine Soft rubber brush (inside) Recharging dock Tiny brush USB charging cable Dust box (inside machine) Battery Dust screen (inside machine) (inside dust box) Remote control Mop pads x 2 Side brush x 4 Quick guide Overview Of Machine Infrared sensor Recharging... -
Page 3: Charging Operation
Start button Collision strip Charging port Overview of recharging dock Signal box Indicator light Infrared projector Charging port Charging contactor Charging Operation Direct charging of host Connect USB charging cable into the USB slot on the power. Connect the other end of USB charging cable into the charging port on the host. -
Page 4: Remote Control
Installation of recharging dock : Connect USB cable into the USB slot on the power and charging port on the recharging dock, the indicator light is ON. Note: Place the recharging dock at flat ground and make its back against the wall without any item in the area (1 meter away from the left and right, 1.5 meter away from the front), and place the USB charging cable along the wall side regularly and neatly, not getting winded to prevent the recharging of the machine. - Page 5 Power Shutdown : When the machine is working, long press button for 2 seconds, the machine stop working. Activation : When the machine in sleep mode, long press button for 2 seconds, machine LED blue light will bright and start working. Recharging Long press button for 2 seconds, machine stop working and the LED blue light will flash, machine connection to recharging dock...
- Page 6 In automatic cleaning mode, the path planning as follow : Random → Spot → Random → Zigzag → Random → Edge Circulation Random cleaning Spot cleaning Zigzag cleaning Edge cleaning Installation and disassembling of brushes : Press the round brush directly into the center convex shaft of the brush base.
-
Page 7: Care And Maintenance
8cm at the bottom to prevent the machine go to stuck. Protective plate shall be placed on the edge of penthouse to ensure safety operation of the machine. Specifications Model : RVC-1409-HC Power : 12W Working Voltage : DC 7.4V... - Page 8 Bahasa Malaysia Pengenalpastian Bahagian Mesin utama Berus getah lembut (di dalam) Dok pengecasan semula Berus kecil Kabel pengecasan USB Kotak habuk (di dalam mesin) Bateri Skrin habuk (di dalam mesin) (di dalam kotak habuk) Alat kawalan jauh Pad pengelap lantai x 2 Berus sisi x 4 Panduan Ringkas Pandangan Keseluruhan Mesin...
- Page 9 Butang mula Jalur perlanggaran Port pengecasan Pandangan keseluruhan dok pengecasan semula Kotak isyarat Lampu penunjuk Projektor infra merah Port pengecasan Penyentuh pengecasan Operasi Pengecasan Pengecasan langsung hos Sambungkan kabel pengecasan USB ke dalam slot USB pada kuasa. Sambungkan hujung kabel pengecasan USB pada hujung satu lagi ke dalam port pengecasan pada hos.
-
Page 10: Alat Kawalan Jauh
Pemasangan dok pengecasan semula: Sambungkan kabel USB ke dalam slot USB pada kuasa dan port pengecasan pada dok pengecasan semula, lampu penunjuk akan HIDUP. Catatan: Letakkan dok pengecasan semula di atas lantai yang rata dan bahagian belakangnya ke dinding tanpa sebarang item dalam kawasan berkenaan (1 meter jauh di kiri dan kanan, 1.5 meter jauh dari hadapan), dan sentiasa letakkan kabel pengecasan USB dengan kemas di sepanjang sisi dinding agar... -
Page 11: Arahan Operasi
Kuasa Penutupan: Semasa mesin sedang beroperasi, tekan butang selama 2 saat, mesin akan berhenti beroperasi. Pengaktifan: Apabila mesin dalam mod tidur, tekan butang selama 2 saat, lampu biru LED mesin akan menyala dengan terang dan mula beroperasi. Pengecasan semula Tekan butang selama 2 saat, mesin akan berhenti beroperasi dan lampu biru LED akan berkelip, sambungkan mesin ke dok pengecasan semula dan masukkan ke mod pengecasan semula. - Page 12 Dalam mod pembersihan automatik, perancangan laluan adalah seperti berikut: Rawak → Setempat → Rawak → Zigzag → Rawak → Tepi Peredaran Mod pembersihan Mod Setempat Automatik Mod Zigzag Mod tepi Pemasangan dan penyahhimpunan berus: Tekan berus bulat terus ke dalam aci cembung teras dasar berus.
-
Page 13: Penjagaan Dan Penyelenggaraan
8 cm di bahagian bawah untuk mengelak mesin daripada tersekat. Plat pelindung hendaklah diletakkan di tepi emper bagi memastikan pengendalian mesin yang selamat. Spesifikasi Model : RVC-1409-HC Kuasa : 12W Voltan Operasi : DC 7.4V Input Pengeecasan : DC 5V 1A ke atas... - Page 14 Marketed by : IN & EX HOLDINGS SDN. BHD. ( 496703-U ) No. 48-3, Jalan PJU 5/10, Dataran Sunway, Kota Damansara, 47810 Petaling Jaya, Selangor D. E. , Malaysia. Tel : (603) 6141 6802 E-mail: info@hetch2u.com Facebook : hetch...
