- Page 1 HETCH Upright Stick & Handheld Vacuum Cleaner (user manual) Upright Stick & Handheld Vacuum Cleaner Model no. : HVC-1404-HC Size : 160 x 105mm Paper : 230gsm Art Card (cover matt laminate)
- Page 2 . Important Safety Instructions . Parts Identification . Safety Advice And Warning . Instruction For Use . Care & Maintenance . Troubleshooting . Specifications . Warranty Card Page : 2...
-
Page 3: Important Safety Instructions
A. IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING YOUR VACUUM CLEANER WARNING: To reduce the risk of fire, electrical shock, or injury: Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing. Do not use outdoors or on wet surfaces. - Page 4 A. IMPORTANT SAFETY INSTRUCTIONS Do not use without dust cup and/or filters in place. Look on your vacuum and follow all label and marking instructions. Keep end of hose, wands and other openings away from your face and body. Always unplug this appliance before connecting or disconnecting vacuum hose. Store the vacuum indoors.
-
Page 5: Parts Identification
B. PARTS IDENTIFICATION 1. Handle 2. Metal Tube 3. ON/OFF Switch 4. Dust Cup Release Button 5. Body 6. Dust Cup 7. Floor Brush 8. 2 in 1 Crevice Nozzle/Brush 9. Flexible Hose 10. Upholstery Nozzle 11. Shoulder Strap Page : 5... - Page 6 C. SAFETY ADVICE AND WARNING This appliance is specialized for domestic use. Use the appliance only on the voltage specified on its rating plate. Do not vacuum the following things : Water and other liquid DO not use the appliance to vacuum lighted matches, cigarette ends or hot ashes DO not use the appliance to vacuum sharp objects Keep the appliance far away from heat sources.
- Page 7 D. INSTRUCTION FOR USE Preparation 1. Assembling for hand holding a. Insert 2 in 1 crevice nozzle/brush or upholstery nozzle into the dust cup (Attach hose for extended distance vacuum function with shoulder strap) b. Hold the body with your hand 2.
-
Page 8: Operation
D. INSTRUCTION FOR USE b. Insert stick into body Operation Slider the power switch, the cleaner begins working. Switch Page : 8... - Page 9 D. INSTRUCTION FOR USE Using of accessories 1. Floor brush For cleaning all types of flat surfaces. 2. Crevice nozzle & Brush nozzle For cleaning radiators, corners, edges, drawers, etc.. 3. Upholstery Nozzle For cleaning on mattresses, sofas and other fabric based pieces. 4.
-
Page 10: Care And Maintenance
E. CARE & MAINTENANCE Empty and clean the dust cup Always operate the vacuum cleaner wuth dust cup installed. Disconnect from electrical outlet before empty dust. When the dust cup is dirty or full, please empty it in time. Press dust cup release button then tilt dirt cup down and away from unit. Dust cup release button Dust cup 5. -
Page 11: Cleaning Filter
E. CARE & MAINTENANCE Cleaning Filter Filter should be rinsed clean at least twice a year or when it becomes visibly solid. Always operate the cleaner with filter installed. Otherwise, this may reduce suction or damage the motor. Disconnect from eletrical outlet before cleaning filter. DO not use the washing machine for rinsing filter, or use a hair dryer for drying it. -
Page 12: Troubleshooting
F. TROUBLESHOOTING Problem Possible Cause Solution Dust in the filter Clean the dust in the filter Replace the dust cup or Weak suction Dust cup full throw off dust Obstacles in the hose Remove all obstacles Motor not working The plug is not connected Insert the plug into the with the wall socket power socket... -
Page 13: Specifications
G. SPECIFICATIONS Model HVC-1404-HC Rated Voltage 220-240V Rated Frequency 50/60Hz Rated Power 1000W Page : 13... - Page 14 Page : 14...
- Page 15 Page : 15...
- Page 16 Page : 16...
- Page 17 perforation line Page : 17...
- Page 18 perforation line Page : 18...
- Page 19 Page : 19...
- Page 20 HVC-1404-HC Page : 20...
