Courtyard Creations TRS42GR Assembly Instructions Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE INTENDED FOR RESIDENTIAL USE ONLY.
Warning: If the information in this manual is not followed exactly, a fire or explosion
!
may result causing property damage, personal injury, or loss of life.
• Do not store or use gasoline, or other flammable vapors and liquids, in the vicinity
of this or any other appliance.
An Propane-cylinder not connected for use shall not be stored in the vicinity of this
or any other appliance.
DANGER: FIER OR EXPLOSION HAZARD
!
If you smell gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, leave the area immediately.
• After leaving the area, call your gas supplier or fire department.
Failure to follow these instructions could result in fire or explosion, which could cause
property damage, personal injury, or death.
Warning: Improper installation, adjustment, alteration, service or maintenance can
!
cause property damage, personal injury or loss of life. Refer to the owner's information
manual provided with this appliance. Installation and service must be performed by a
qualified installer, service agency, or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
DANGER
!
Use the correct bolts as indicated. Do not tighten any of the bolts until the appliance is completely assembled.
Do not sit or stand on this appliance.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Do not use indoors or inside of any enclosure.
Retain these assembly instructions for future reference.
Installer - Leave these instructions with the owner.
Quote the following FQC No. when contacting the service center.
E-2
TRS42GR
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has
no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space; such as
a camper, tent, car, or home.
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
PAGE 1 OF 8
WARNING: For Outdoor Use Only
!
Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
COURTYARD CREATIONS INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRS42GR and is the answer not in the manual?

Questions and answers

Related Manuals for Courtyard Creations TRS42GR

Summary of Contents for Courtyard Creations TRS42GR

  • Page 1 Retain these assembly instructions for future reference. Installer - Leave these instructions with the owner. Quote the following FQC No. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 PAGE 1 OF 8 COURTYARD CREATIONS INC.
  • Page 2 When an appliance is for connection to a fixed WARNING piping system, the installation must conform with local codes or, in the absence of local codes, with If the appliance is not in use, the gas must be turned the National Fuel Gas Code, ANSI Z223.1 NFPA off at the supply cylinder.

  • Page 3: Parts List

    PARTS LIST PART PART MATERIAL CODE PART Q’TY MATERIAL CODE PART Q’TY TRS42GR-CS10-3 17C40A0714001YX REAR FRAME BOLT M6*40 TRS42GR-CS04-J 17C40A0709001YX FRAME A BOLT M6*25 TRS42GR-CS04-K 17C40A0705001YX FRAME B BOLT M6*15 17C17A1506001YX TRS42GR-CS10-9 BOTTOM FRAME SCREW ST4.8*16 17KAA0101----Y4 TRS42GN-CS10-5 HEX. KEY WRENCH 4MM...
  • Page 4 FIGURE 2 FIGURE 3 #11 BOLT M6*25 Step 2: Fasten the bottom frame (#4) and the cross brace (#18) to frames (#2 and #3) by using screws (#13) and bolts (#11). See Figure 2. #12 BOLT M6*15 FIGURE 4 Step 3: Fasten the lower connector (#7) to the corner of the bottom rim of the frame B (#3) by using bolt (#12).
  • Page 5 FIGURE 6 FIGURE 7 Caution: The Tank must face this way. Rotate Plastic Clockwise Screw Step 6: Step 7: Open the front door (#5) and place the tank into the Attach the table top (#6) to the tank by rotating bottom frame (#4).

  • Page 6: Specific Warnings

    WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. SPECIFIC WARNINGS: 1) Both children and adults should be aware of the hazards of high surface temperatures and should keep their distance in order to avoid burns and ignition of clothing.

  • Page 7: Safety Instructions

    Warranty • This product is covered by Courtyard Creations Inc.'s. one–year limited warranty. • Proof of purchase (dated register receipt) is required for warranty claims. • It remains the customer’s responsibility for freight and packing charges to and from the service center.

  • Page 8: Care Instructions

    INSTRUCTIONS FOR REMOVING THE TANK FIGURE A FIGURE B Counter-Clockwise Plastic screw Step B: Note: Remove the tank from the tank support Close the valve tightly before removing the tank. assembly and through the tank fastener. Step A: See Figure B. To remove the fuel supply hose from the tank, Note: rotate counter-clockwise.
