ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
WARNING: For your safety, this product is for outdoor use only.
Do not use indoors, and outside any enclosure.
Refer to local codes and/or the authority having
jurisdiction for outdoor burning use.
Use heat-resistant gloves or hotpads when using
handles and air vents.
Use long, sturdy fireplace tools when adding or
moving logs.
Use the correct bolts as indicated. Do not tighten any of the bolts until the table is
completely assembled.
Do not sit or stand on this table.
Do not discard of any of the packaging until you have checked that you have all of the parts
and fittings required.
Keep children away during assembly. This item contains small parts that can be
swallowed by children. Children should always be under direct adult supervision while
using this product.
Retain these assembly instructions for future reference.
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
TCS46JK
!
WARNING
FOR YOUR SAFETY:
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
-WM
PAGE 1 OF 6
COURTYARD CREATIONS INC.
Advertisement
Related Manuals for Courtyard Creations TCS46JK-WM
Summary of Contents for Courtyard Creations TCS46JK-WM
- Page 1 Retain these assembly instructions for future reference. Quote the following FQC NO. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 DON’T RETURN TO STORE! STOP COURTYARD CREATIONS INC. PAGE 1 OF 6...
-
Page 2: Parts List
PARTS LIST PART PART MATERIAL CODE PART Q’TY MATERIAL CODE PART Q’TY TCS46JK-CS06 17C33A0709001Y4 TABLE TOP BOLT M6*25 TCS47JK-CS02 17FA05040301-Y4 WASHER d6.5*D13*1.0 62TCS47JKY101 17FD05040301 CENTER CONNECTOR WASHER d6.5*D13*1.0(BLACK) 17FD05020601 13C??B30008001 TILE WASHER d6.5*D10*1.6 13C??1B29008001 18000C23001 TILE PLASTIC NUT M6*P1.0 TCS46JK-CS01 17D02D030302 COVER NUT M6... - Page 3 FIGURE 1 ATTENTION: Make sure that each bolt needed for all steps matches the corresponding figure to ensure proper assembly. NOTE: There are some parts in other carton. Step 1: Place the table top (#1) onto a non-abrasive surface, such as a carpet, with its underside facing upwards. Fasten the legs (#2) to the table top (1) rim by using bolts (#10), washers (#12) and plastic nuts (#15).
- Page 4 WARNING : FIGURE 4 The edges of tiles may be sharp, please wear protective gloves before open the cartons. Step 4: Fasten the handle (#18) to the spark guard (#8) by using washers (#13 and #14) and nut (#16). Put the fire bowl (#7) into the table top, cover the fire bowl with a spark guard (#8).
-
Page 5: Carbon Monoxide Hazard
FIGURE 7 Step 7: When you use ice to freeze the drink and fruit, remove the cover (#6) and the spark guard (#8) from the fire bowl, position the plastic cooler (#9) onto the fire bowl (#7). Put the residual parts (#6 and #8) to the center connector. -
Page 6: Operating Your Outdoor Fireplace
Operating your outdoor fireplace Before lighting: Always use in accordance with all applicable local and national fire codes. Use on noncombustible surfaces such as concrete, brick, or rock. Use extreme caution when using on a wooden deck. Do not leave unit unattended at any time. Keep all screws and nuts tight, and inspect on a regular basis to be sure fireplace is in safe working condition.
