Field wiring, signal termination and conditioning

You can use the following MCC screw terminal boards with the PCI-CTR05 board using the C37FF-x or
C37FFS-x cable.

SCB37 — 37-conductor, shielded signal connection/screw terminal box that provides two independent 37-
pin connections.

CIO-MINI37 — 4 x 4, 37-pin screw terminal board.

CIO-MINI37-VERT — 37-pin screw terminal accessory with vertical 37-pin male D connector.

CIO-TERMINAL — 16 X 4 universal screw terminal board with on-board prototype area and circuitry.
Details on these products are available on our web site.
The red stripe
identifies pin # 1
Figure 3. C37FF-x cable
Figure 4. C37FFS-x cable
11
