INSTRUCTION MANUAL
P
LEASE READ ALL THE INSTRUCTIONS COMPLETELY BEFORE USE.
THE LIGHTNING
FLASH AND ARROW-
HEAD WITHIN THE
TRIANGLE IS A WARN-
ING SIGN ALERTING
YOU OF "DANGEROUS
VOLTAGE" INSIDE THE
RADIO.
WARNING:
FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR
MOISTURE.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE
RISK OF ELECTRIC
SHOCK, DO NOT REMOVE
THE RADIO BACK. NO
USER SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
TO PREVENT
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A WARN-
ING SIGN ALERTING
YOU OF IMPORTANT
INSTRUCTIONS
ACCOMPANYING THIS
RADIO.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCRadio plus and is the answer not in the manual?

Questions and answers

Related Manuals for C. Crane CCRadio plus

Summary of Contents for C. Crane CCRadio plus

  • Page 1 INSTRUCTION MANUAL LEASE READ ALL THE INSTRUCTIONS COMPLETELY BEFORE USE. THE LIGHTNING FLASH AND ARROW- HEAD WITHIN THE TRIANGLE IS A WARN- ING SIGN ALERTING YOU OF “DANGEROUS VOLTAGE” INSIDE THE RADIO. WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
  • Page 2 Copyright © 2002 by C. Crane Company, Inc., Fortuna, CA 95540 800-522-8863 • ccrane.com All rights reserved. No part of this booklet may be reproduced, in any form or means whatsoever, without permission in writing from C. Crane Company, Inc.

  • Page 3: Table Of Contents

    ABLE OF ONTENTS AFETY NSTRUCTIONS NTRODUCTION NPACKING UTTON DENTIFICATION ETTING TARTED OWERING NSTALLING ISPLAY ETTING ETTING NOOZE LEEP IMER ADIO PERATION UNING EATHER ISPLAY WITCH EADPHONE ESET UTTON UDIO & ETTING NSTRUCTIONS HARGING ATTERY PECIFICATIONS ADIO OISE ROUBLESHOOTING ISTENING ERSONAL TATION ADIO ATTERIES...

  • Page 4: Safety Instructions

    READ BEFORE OPERATING EQUIPMENT 1) Read and understand all safety and operating instructions before the radio is operated. 2) Retain Instructions: The safety and operating instructions should be retained for future reference. 3) Heed Warnings: All warnings on the appliance and operating instruc- tions should be followed.
  • Page 5 10) Do not overload wall outlets or extension cords. This can result in a risk of fire or electrical shock. Never insert objects of any kind into the receiver through openings. The objects may touch dangerous voltage points or short out parts. This could cause a fire or electrical shock. 11) If the radio is left unattended and unused for long periods of time, unplug it from the wall outlet.

  • Page 6: Introduction

    NTRODUCTION Thank you for purchasing the high per- formance digital CCRadio CCRadio incorporates the highest plus quality parts and superior engineering to produce the most sensitive AM receiver available. It also covers FM Stereo, Weather, and TV audio chan- nels 2-13. The special Weather Alert System may sound an alarm if a signal is broadcast from National Oceanic and Atmospheric Administration (NOAA) in...

  • Page 7: Button Identification

    UTTON DENTIFICATION 1) Clock Set 2) Alarm/Set 3) Timer/Set 4) Display Clock or Frequency 5) Bass Control 6) Treble Control 7) Tuning/ Time Set (Up/Down) 8) Headphone Jack 9) Volume Control Note: When you see a “ the radio, it means you must hold the button down to activate the function.

  • Page 8: Getting Started

    ETTING TARTED OWERING Before powering your radio be sure to read the Safety Instructions on pages 4 and 5. The CCRadio will run on (4) “D” size NiCad or alkaline batteries or plus on 120V AC house current using the included power cord. Batteries are optional.

  • Page 9: Installing The Display Panel

    NSTALLING 1) Position the radio face down on a soft surface to protect it. 2) Remove the battery compartment cover. 3) Insert the (4) “D” cell batteries into the compartment as indicated in the drawing below. Be sure the negative (-) end is against the spring.
  • Page 10 1) Weather Alert Modes 2) Memory Location (1 - 5) 3) Key Lock On/Off 4) Sleep Timer/Snooze Status 5) Battery Symbol 6) Battery Power Level Indicator and Signal Strength Meter 7) Timer Active Indicator Page 10 ISPLAY ANEL 8) Clock Seconds 9) Frequency / Clock Display 10) Alarm Status and Type 11) AM/PM Indicator...

  • Page 11: Setting Thec

    ETTING LOCK Please read this entire section carefully before you start. Set the time with the radio off. You will need to go through the steps listed below with- out stopping for more than 15 seconds at any given time or you will have to start over.

  • Page 12: Snooze Feature

    OTES You can also set the alarm time immediately after selecting the radio or buzzer alarm as described on page 11. To stop the alarm from going off every day, press and hold the Alarm Button until ALARM disappears from the display. Once the alarm is set, it will automatically go off the next day at the same time.

  • Page 13: Radio Operation

    ADIO PERATION The CCRadio features four bands: AM / FM / TV Audio 2-13 and plus Weather. ANUAL UNING 1) Press the Power Button to turn on the radio. 2) Select the band by pressing the Band Button. 3) A single press of the Up or Down Tuning Buttons will change the frequency up or down for AM and FM bands, and channel up or down for Weather and TV bands.

  • Page 14: Weather Alert

    EATHER LERT The WEATHER ALERT modes on the CCRadio special weather related emergencies. During an emergency or weather related hazard, NOAA issues an emergency tone that will set off an audible and/or visual alarm on the radio. NOTE: Hazard warnings are not available in all areas. There are seven standard NOAA weather channels used in the US and Canada.
  • Page 15 This is WEATHER ALERT mode with flashing light only (no Alarm). If NOAA issues a weather related emergency, the radio will automatically alert you with a small flashing light near the top of the radio. The Alert light continues to flash until any button is pushed. 2) To access the second mode, (WEATHER ALERT with NOAA Audio).

  • Page 16: Display Light

    ISPLAY IGHT AC P ISPLAY IGHT ON When the radio is plugged into AC power, the display light will always be on unless you turn it off. The special green LED bulbs last about 100,000 hours and use very little want to turn off the display light, press the Light button.

  • Page 17: Aux In Jack

    & R UDIO ECORDING The jacks on the back, left side of the radio are for audio input (AUX IN), audio output (LINE OUT) and a timer activation switch AUX IN Jack Timer Activation Switch LINE OUT Jack AUX IN J The green jack, labeled AUX IN is used to connect an external audio source such as a CD Player or recorder, so you can listen through your CCRadio...

  • Page 18: Setting Thet

    through the other source. You can still listen to the CCRadio while using the LINE OUT jack. TIMER ACTIVATION SWITCH The black jack labeled with this symbol has a timer activated switch. You would use this switch if you wanted to do a timed recording.

  • Page 19: Instructions Forl

    The timer will go ON and OFF at the same time and same station every day until you turn the timer off or reprogram it. IMER If TIMER is showing on the display then the Timer is set. Press and hold the Timer/Set Button until you hear a short beep and the word TIMER disappears from the display.
  • Page 20 light will extend up to 12’. Just pull on the connector and unreel it to the desired length. The black base of the light opens up to reveal a handle that is used to reel the cord back in. The base is also a magnet, so you can mount it to any metal surface like a refrigerator or a car.
  • Page 21 Run Times And Charge Times For NiCad Batteries CCRadio with heavy duty NiCad batteries ... Approx. 48 Hrs. plus Approx. time to charge NiCad batteries with AC Adapter ... 27 Hrs. Approx. time to charge NiCad batteries with Solar Panel ... 67 Hrs. Times are approximate.

  • Page 22: Specifications

    PECIFICATIONS REQUENCY OVERAGE FM Band: 87.5 - 108 MHz Stereo AM Band: 520 - 1710 kHz TV Band: Channels 2-13 Audio Only EATHER Channel 1: 162.400 MHz Channel 2: 162.425 MHz Channel 3: 162.450 MHz Channel 4: 162.475 MHz OTARY UNING AM - 1 kHz TV - 1 Channel...

  • Page 23: Line-In Jack

    ERSA ORDER Dual speed tape recorder. Designed to work with CCRadio plus. Record up to 4 hours on one side of a cassette tape. Can be purchased directly from C. Crane Company Inc.at 1-800-522-8863 or on the web at ccrane.com.

  • Page 24: Roubleshooting

    ADIO OISE ROUBLESHOOTING Annoying buzzes are many times transmitted through an AM radio. Here is a check-off list of the most likely causes: • Dimmer switch. • Fluorescent light. • “Touch lamp” type light fixture (even when turned off). • Automatic on and off night lights. •...
  • Page 25 AM T & L UNING Most portable radios including the CCRadio antenna. Best performance is achieved when the radio is swiveled on its base for maximum signal pickup from the transmitting tower. This same technique can be used to help nullify unwanted signals or radio noise. Experimentation is the best way to see how it works for you.

  • Page 26: Personal Station Log

    ERSONAL TATION Station Time City Frequency Date Call Letters Please feel free to copy this page. Page 26...
  • Page 27 Model: CCRadio plus FCC ID: BYG 003 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS. 1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
