INSTRUCTION MANUAL
P
LEASE READ ALL THE INSTRUCTIONS COMPLETELY BEFORE USE.
THE LIGHTNING
FLASH AND ARROW-
HEAD WITHIN THE
TRIANGLE IS A WARN-
ING SIGN ALERTING
YOU OF "DANGEROUS
VOLTAGE" INSIDE THE
RADIO.
WARNING:
FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR
MOISTURE.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE
RISK OF ELECTRIC
SHOCK, DO NOT REMOVE
THE BACK. NO USER SER-
VICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE PER-
SONNEL.
TO PREVENT
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A WARN-
ING SIGN ALERTING
YOU OF IMPORTANT
INSTRUCTIONS
ACCOMPANYING THIS
RADIO.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCRadio and is the answer not in the manual?

Questions and answers

Related Manuals for C. Crane CCRadio

Summary of Contents for C. Crane CCRadio

  • Page 1 INSTRUCTION MANUAL LEASE READ ALL THE INSTRUCTIONS COMPLETELY BEFORE USE. THE LIGHTNING FLASH AND ARROW- HEAD WITHIN THE TRIANGLE IS A WARN- ING SIGN ALERTING YOU OF “DANGEROUS VOLTAGE” INSIDE THE RADIO. WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
  • Page 2 Copyright © 1998-2000 by C. Crane Company, Inc., Fortuna, CA 95540 All rights reserved. No part of this booklet may be reproduced, in any form or means whatsoever, without permission in writing from C. Crane Company, Inc. ccrmanual.qxd Rev 6/00...

  • Page 3: Table Of Contents

    ABLE OF ONTENTS AFETY NSTRUCTIONS ......6 NTRODUCTION ......6 NPACKING UTTON DENTIFICATION...

  • Page 4: Safety Instructions

    READ BEFORE OPERATING EQUIPMENT 1) Read and understand all safety and operating instructions before the radio is operated. 2) Retain Instructions: The safety and operating instructions should be retained for future reference. 3) Heed Warnings: All warnings on the appliance and operating instruc- tions should be followed.
  • Page 5 not the cord. Operate the radio using only the correct type of power source indicated. If you are not sure of the type of power supply to your home, consult your dealer or local power company. 11) Do not overload wall outlets or extension cords. This can result in a risk of fire or electrical shock.

  • Page 6: Introduction

    NPACKING The box should contain the CCRadio, the power cord and this manual. If anything is missing or damaged please contact your dealer immedi- ately. We recommend you keep the box in the unlikely event your radio will need servicing.

  • Page 7: Button Identification

    UTTON DENTIFICATION 1) Display Light 2) Display Time or Frequency 3) Sleep Timer 4) Band / Time Set 5) Treble Control 6) Bass Control 7) Manual / Auto Seek 8) Headphone Jack 9) Volume Control UTTON DENTIFICATION 10) Lock Button 11) Tuning Knob 12) Power Button 13) Telescopic Antenna...

  • Page 8: Getting Started

    Before powering your radio be sure to read the Safety Instructions on page 4. The CCRadio will run on (4) “D” size nicad or alkaline batteries or on 120V AC house current using the included power cord. Batteries are optional. The batteries are necessary to keep the time clock and memories if the power cord is removed from the radio for more than three minutes.

  • Page 9: Nstalling He Atteries

    NSTALLING 1) Position the radio face down on a soft surface to protect it. 2) Remove the battery compartment cover. 3) Insert the (4) “D” cell batteries into the compartment as indicated in the drawing below. Be sure the negative (-) end is against the spring.

  • Page 10: Display Panel

    1) Battery Power Level Indicator 2) Time Is Displayed 3) Sleep Timer 4) Snooze Status 5) Memory Location/Sleep Timer Minutes/Clock Seconds 6) Frequency Unit Page 10 ISPLAY ANEL 7) Key Lock On/Off 8) Tuning Indicator 9) Frequency / Clock Display 10) Alarm Status 11) AM/PM Indicator 12) Indicates Band In Use...

  • Page 11: Setting The Clock

    This also sets the seconds to “00”. ETTING LARM There are two different alarm modes on the CCRadio. You can choose to wake up to the radio or to a tone. You can set the alarm with the radio on or off.

  • Page 12: Snooze Feature

    LEEP IMER EATURE Your CCRadio is equipped with a Sleep Timer that enables the radio to continue playing for up to 90 minutes after activation, then shuts the radio off. Selectable times are 90, 60, 30 and 15 minutes. To utilize this feature, have the radio on and tuned to the station you want to listen to, then press the button that has the pictogram of a person in bed.

  • Page 13: Radio Operation

    ADIO PERATION The CCRadio features four bands: AM / FM / TV 2-13 and Weather. ANUAL UNING 1) Press the POWER button to turn on the radio. 2) Select the band by pressing the BAND button. 3) A single press of the Up or Down tuning button will change the frequency up or down for AM and FM bands, channel up or down for weather and TV bands.

  • Page 14: Weather Alert System

    EATHER LERT The unique WXALERT mode on the CCRadio will alert you to special weather related emergencies. During an emergency or weather related hazard, NOAA issues an emergency tone that will set off an audible and/or visual alarm on the radio.

  • Page 15: Display Light

    near the top radio comes on continuously: WXALERT with Alarm and flashing light will be active. Display shows ALERT and red light near the top of the radio. In this mode, if the NOAA alert tone is issued, the red light on the top of the radio flashes and a siren turns on for 1 minute.

  • Page 16: Lock Switch

    You will lose the clock time, and all the stations stored in memory when the radio is reset. Page 16 Lock Switch Reset Button Bottom View of CCRadio Headphone Jack...

  • Page 17: Specifications

    PECIFICATIONS REQUENCY OVERAGE FM Band: 87.5 - 108 MHz Mono Only AM Band: 520 - 1710 KHz TV Band: Channels 2-13 Audio Only EATHER Channel 1: 162.400 MHz Channel 2: 162.425 MHz Channel 3: 162.450 MHz Channel 4: 162.475 MHz OTARY UNING AM - 1 KHz...

  • Page 18: Listening Tips

    Experimentation is the best way to see how it works for you. Top View CCRadio The CCRadio has two external antenna terminals for AM. If your recep- tion is better outside, for a quick and easy antenna use 50’ of insulated wire attached to one terminal and a ground to the other terminal.

  • Page 19: Adio Oise Roubleshooting

    ADIO OISE ROUBLESHOOTING Annoying buzzes are many times transmitted through an AM radio. Here is a check-off list of the most likely causes: • Dimmer switch. • Fluorescent light. • “Touch lamp” type light fixture (even when turned off). • Automatic on and off night lights. •...

  • Page 20: Personal Station Log

    ERSONAL TATION Station Time City Frequency Date Call Letters Please feel free to copy this page. Page 20...
  • Page 21 Model: CCRadio FCC ID: BYG 002 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS. 1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
