INSTALLATION INSTRUCTIONS
Diverter with ceramic lever -
Important
● We recommend that this product is installed by a qualified professional contractor. Such as a plumber who is certified by NVQ
(National Vocational Qualification) or SNVQ (Scottish National Vocational Qualification) Level 3.
● Please check this product immediately to ensure that it has not been damaged and is complete. Before installation, please make
sure this product is the correct model and you have all the parts required for installation and using.
● Please read these instructions carefully and keep it for future reference.
Installation
DIVERTER
HANDLE
Dimension
Maintenance
We do NOT recommend you use any household cleaners to clean the product. Because these cleaners change substance or formula
too frequently. The product should be always cleaned only with soapy water and rinsed with clean water and dried with a soft cloth.
V31
COMPRESSION
NUT
BRASS RING
OUTLET
BRASS RING
TUBE
COMPRESSION
NUT
40.5
Ø18
1 - 1
RISER (V21 or V22)
FLEXIBLE HOSE (V26)
B
