Burlington T30 CHR Assembly

Assembly
● Mount the cistern securely on the wall at the height of 2060mm from the underside of
the cistern to the floor using the fixing holes through the rear of the cistern (See hint 1).
● Join the two flush pipes together and silicone the joint.
● Use the brass fixing nut (as part of the decorative cover) to fix in the cistern fittings.
Place the
decorative cover
washer (supplied as parts of the cistern fittings) over the top of the flush pipe (longer
end of the flush pipe) and insert into the threaded siphon stem (supplied as part of the
cistern fittings). Once the flush pipe is secured by the plastic fixing nut, screw the
up to the brass fixing nut.
decorative cover
● Insert the lower end of the flush pipe into the pan via the flush cone (supplied as part
of the cistern fittings).
● Locate the buffer clip so as to prevent collision between the seat and flush pipe. This
buffer clip will also secure the flush pipe to wall by fixing the buffer clip upto wall.
● Put in the control bracket first, then join the pull handle to the lever arm. Fix the
control bracket to the wall 180mm above the pull handle.
● Mount the ornate brackets using the screws provided snugly under the cistern
(See hint 2).
1. When installing your cistern, ensure that the rubber spacing washers are used to create
a small gap between the cistern back and the wall. There are two reasons for this; firstly it
will help to reduce the possibility of condensation when cold mains pressure is contained
within a humid environment and secondly, the gap will help prevent "thermal shock". This is
when rapid temperature change occurs (usually overnight) and causes the wall to contract
or expand, thus cracking the sanitaryware. When fixing the cistern to the wall it is advisable
to insert the screw through a washer (not supplied) on the inside of the cistern. This will
prevent the screw damaging the sanitary ware when the screw "bites".
* If required, for example if the wall is not level, please add additional spacers which are not
provided to ensure the cistern is level for fixing to the flush pipe.
2. The ornate brackets are purely decorative. They should not be used as support for the
cistern. Always ensure that the cistern is firmly and securely fixed to the wall via the fixing
holes at the rear of the tank.
and plastic fixing nut, plastic washer, cone shaped
HANDY HINT
1 - 3
High Level Flush Pipe kit T30 CHR
