Tiger TPK-01 User Manual

Thank you for purchasing our scale. With normal care and proper treatment, it
will provide years of reliable service. Please read all operating instructions
carefully before use.

SPECIFICATIONS

Capacity: 300g*0.01g, 500g*0.01g, 3kg*0.1g,
Units: g/oz/lb/kg/tl/ct
Tare range: 100%FS
Auto off (default): 60 seconds
Operation temperature: 5-35℃
Display: LCD 5 digits

OPERATIONS

Weighing Items

1. Place scale on a horizontal flat surface, press ON/OFF switch
2. Wait until "0.0" is displayed
3. Put the object(s) on the weighing platform
Counting(PCS)
1. Put the relevant amount of goods that you are going to count as the sample
(25,50,75,100).
2. Press and hold "pcs" key for two seconds, then you will see "100".
3. Press "MODE" key and you will see "25, 50, 75,100". Please select the
number that you are willing to put as the sample number. Then press "PCS"
key to confirm it.
4. Now you can put the goods that you want to count on the center of the
platform and the LCD will show the actual number of the goods on the
platform.

MODE - Change unit

press the "MODE" key to toggle the weighing unites between g, oz, lb, kg, tl
and ct.
