SIMPLICITY PLUS / SIMPLICITY MICRO – ADDITIONAL FEATURES.

10 VIEWING PANEL INFORMATION

10.1 Menu Structure

To help locate the different features available, the menu structure of the simplicity panel is shown here.
MENU LAYOUT
MAIN MENU SUB MENU 1
CONFIGURATION MENU 1 – THE USER MENU
1:Loop Contents -
2:Device Status -
3:Event logs VIEW EVENT LOG
1: Alarms
2: Faults
3: System
4: All
CONFIGURATION MENU 2 – THE ENGINEER MENU
4:Configure Loops -
5:Edit Device -
6:Config System System Menu
1: Clock
2: Zones
3: Alarms
4: Timing
5: Misc
6: Reset
Approved Document No: GLT.MAN-139
Issue 1.00 Authorised: GH
SUB MENU 2
-
-
-
-
-
-
-
-
-
-
Alarm Operation
1: Det
2: MCP
3: SOUNDER
4: Bases
5: I/O
Alarm Timing
1: Zonal to Common
2: Alarm Verify
Misc Settings
1: Language
2: Version Info
Reset Settings
1: Logs
2: Zones
3: Panel
4: Devices
6: All
Date: 02/06/2010
DESCRIPTION
View quantity of each device type configured on
the loop
View the status of an individual device (Status –
normal/fault/alarm, Analogue value, device label
View all fire alarm events
View all fault events
View all other events (eg keyswitch on, menu
access, clock change, etc)
View all events
Configure the loop
Edit device label (press enter for cursor)
Turn on detector LED
Ring associated sounder
Select alarm verification
Turn off associated sounder at this address
Disable this device.
Select specific I/O Operation for an I/O unit
Adjust time & date
Change zone boundaries
Choose detectors to cause zonal alarm or
common alarm for sounders
Choose MCP to cause zonal alarm or common
alarm for sounders
Select if the sounders have a zonal to common
time out when triggered zonally
Select if associated sounder bases work
common or zonal
Select default I/O type
Select the delay for all the sounders to operate
after a zonal alarm
Select alarm verification time
Select LCD language
Displays the firmware versions
Erases event logs
Resets the default zone boundaries
Resets panel to default alarm & timing settings
Erases loop contents from memory, clears
device labels, resets verification & sounder base
settings to default.
Resets all configuration settings, but preserves
event log.
Software Version :PANEL-R6180 (Plus) R5780 (Micro)
