Bird Cage : Canary [Assembly Instructions]
You will need
Scissors, glue, ruler, a used ball-point pen, tweezers
Explanation of symbols
Mountain fold (Dotted line)
Valley fold (Dashed and dotted line)
Scissors line (Solid line)
Cut in line (Red solid line)
Glue tab
Cutout
Assembly tip
Trace along the folds with a ruler and a used
pen (no ink) to get a sharper, easier fold.
Caution: This craft requires the use of glue, scissors, and other tools
which may be dangerous to young children. Please keep them out of
reach of children while you work.
Bird Cage
1) Cut out A1 ~ C2 and assemble each part.
Fold A1 and A2 in half and
attach the back of each side
together respectively.
Make two A1s,
and four A2s.
2) Attach A1 ~ D2.
Attach A1 and A2 to
the back of D1 as shown.
*Attach the two A1s
opposite each other.
3) Cut out E1 ~ E4, and glue them together.
Glue the reverse sides of E1 and
E2 together, and curve the pieces
before the glue dries.
*Glue them together
*Put the E1 side face up.
beginning in the center.
For B1 and B2, fold back the top bumps
and the bottom edge, and glue each part
to the reverse side of the piece.
*Do not glue down the glue tabs.
Cut along the inside lines as shown.
*Be careful not to cut the glue tabs.
Stand the A1 and A2 parts up
at right angles, and attach B1
and then B2.
Attach the back side of D1
to the back side of D2.
Fold E3 in half,
glue the back sides together
and cut out the piece as shown.
For C1 and C2, fold back
the top bumps and glue them
to the reverse side of the piece.
Make three
each of these parts.
Put one C1 and one C2 together as a set,
and glue them around A1/A2,
attaching them to the glue spots.
Only attach two C1/C2 sets.
*Keep one C1/C2 set aside.
Attach E4 so that it covers up
the cut on E3.
Attach E4 to E1.
