Owner's Manual
mLT-30 Mini Laptop Cart
mLT-30 Laptop Cart
55315BW
mLT-30 w/ wire management trays
55319BW
mLT-30 w/ wire management trays & rear locking door
55318BW
CAUTION:
Before using this product, read this manual and follow all safety and
operating instructions.
IMPORTANT:
Before you begin, please make sure all parts and proper quantities are
included. Any parts damaged during shipment must be reported within 15
days of receipt. To report information regarding damages or if you have any
questions, please call 1-800-235-1262.
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
1-800-235-1262
Thank you for choosing Spectrum products!
Spectrum Industries, Inc.
Chippewa Falls, WI 54729, USA
55315BW
mLT-30 Mini Laptop Cart
w/ 5" Balloon Wheels
0105788R9 Page 1 of 12
0105788R9 Page 1 of 12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spectrum Industries mLT-30 55315BW
Summary of Contents for Spectrum Industries mLT-30 55315BW
- Page 1 To report information regarding damages or if you have any questions, please call 1-800-235-1262. To purchase parts or accessories, please contact us at www.spectrumfurniture.com 1-800-235-1262 Thank you for choosing Spectrum products! Spectrum Industries, Inc. Chippewa Falls, WI 54729, USA 0105788R9 Page 1 of 12 0105788R9 Page 1 of 12...
-
Page 2: Hardware Package Contents
Safety Read this owners manual before assembly or operation Do not allow children to move cart Move slowly and carefully when mobile Hardware package contents (14) 052605 (6) 0103920 (1) 025039 (4) 0105648 (100) 0102376 1/4-20 x 15mm JC Bolt 1/4-20 x 1/2"... -
Page 3: Rear Panel Removal
2. Cord Management Bracket Installation A. Attach the cord management brackets to the side panels (left and right-side) with 1/4-20 x 15mm JC bolts Tools Required: as shown in Figure 2A and tighten securely. Be sure the brackets are facing away from each other as shown. B. - Page 4 4. Cord Management & Setup A. Remove the rear panel (or open rear door.) Make sure all power cords are unplugged. B. To wire multiple laptop chargers in a row, stack two chargers together along with the necessary bundled charge cords, and attach to the cart using zip ties and the cord management slots shown in Figure 4A.
- Page 5 Pine-tree Clips Zip Ties Front Door Mini Laptop / Netbook Charge Cord Position #1 Charge Cord Position #3 Charge Cord Charging Position #2 Transformers (Wiring example Zip Ties Zip Ties Charging Mini Laptop / Netbook Transformers (Wiring example Charge Cord Position #1 Charge Cord Position #3...
- Page 6 Worksurface Pine-tree Clips Mini-Laptop / Netbook mLT-30 Mini Laptop cord management front view Figure 4C CAUTION The mLT-30 Mini Laptop Cart features two separate 16-outlet charging circuits on separate cords. Some laptop notebook computers may draw more than amp when fully discharged. If that is the case, plugging the two power cords into separate 15-amp electrical outlets will prevent an electrical overload which may trip a circuit breaker.
- Page 7 mLT-30 Power Cord Management (without optional timer or cord reel) A. Switch off both power strips. B. Route the power strip cords as shown. Figure 5. Use the cord management brackets for excess cords. C. When plugging the power strips into wall outlets, be sure a separate circuit is used for each power strip. D.
- Page 8 mLT-30 Power Cord Management (with optional timer) A. Switch both power strips and the cycle timer off. B. Route the power strip cords as shown and plug one in to the 'A' side outlet, and one into the 'B' side outlet on the timer. Figure 6. (routing these cords behind the power strips will provide easier access to the outlets.) C.
-
Page 9: Using Timer
Value Cycle Timer Operation On / Off Switch (Controls power to timer & 'A' and 'B' outlets) Cycle Switch 15-amp Reset Button Timer Control Left (A) power Right (B) power Auxiliary strip outlet & strip outlet & (constant-power) indicator indicator 2-outlets used for accessories such Note: Each laptop cart power strip... - Page 10 mLT-30 Options Value Cycle Timer Wire Management Trays (3 trays included) Retractable Cord Reel Wire Management Trays Rear Double-Bolt Locking Door 16"W x 6"D x 2"H "W x "D x 30"H (set of 3 trays holds charging (replaces rear panel) transformers and cords) shipping weight: 13 lbs Value Cycle Timer +...
-
Page 11: Technical Specs
Technical Specs Construction ● The worksurface and base panel is constructed from 1 " NAUF (No Added Urea Formaldehyde) composite board with .030 high- pressure laminate on one face, and a balancing phenolic backer on the opposing face ● 16-gauge side panels, shelves, and front door ●... -
Page 12: Warranty
Warranty WE WILL MAKE IT RIGHT FOR YOU! We guarantee all Spectrum products to be free of all defects in materials and workmanship, for the original owner, for a period of ten years. Any item deemed defective by Spectrum or the original manufacturer, under normal use conditions, will be repaired or replaced at Spectrum’s discretion.
