- Page 1 INSTALLATION GUIDE Air Gap KAG-1 KAG-2 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2019 Kraus USA Inc. I REV. DEC 22, 2020...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Toll-Free: 800.775.0703 or customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional. - Page 4 Diagram and Parts List: A. Cap B. Nut & Washer C. Washer D. Nut D. Air Gap Body...
- Page 5 Dimension 1 7/8” 1 7/8“ [46.3mm] [46.3mm]...
- Page 6 Step 1 Remove the cap (A) and nut & washer (B). A & B Step 2 Insert the air gap body (E) through the sink deck hole, leaving 2-1/4" (57 mm) approximately 2-1/4" (57 mm) of the body showing above sink deck. (Back the nut (D) down if necessary).
- Page 7 Step 3 Thread the cap (A) and the nut & washer (B) fully onto body, with the slotted vents (1) facing the A & B wall. Tighten the nut (D) firmly. (F/L) Note: The air gap is to be installed so that the flood level mark (F/L) shall be at or above the flood level of the sink or other receptacle which may be connected to the sanitary drain into...
- Page 8 Replacement Parts Replacement Parts List Finish / Color Part # KP27179 CH, SFS, MB, (For KAG-1) 1. Cap ORB, BG, SB, BB, KP27180 SFACB, SFSB* (For KAG-2) 2. Nut & Washer KP27192 3. Washer KP27182 4. Nut KP27181 *Denotes faucet component color options:...
- Page 9 The warranty commences from the initial date of purchase by the owner or trade professional, from an authorized Kraus dealer, through the one (1) year term of the original owner or end-user. Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus.
- Page 10 (HI, AK, and Puerto Rico shipping charges may apply). International shipping fees are not included. Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
- Page 11 Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 Toll-free 800-775-0703 Customerservice@kraususa.com If you are a PLUMBING CONTRACTOR OR TRADE PROFESSIONAL please contact a Kraus Pro Representative at: Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 516-801-8955 Proservice@kraususa.com...
- Page 12 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration...
