Page 1: Instruction Manual
Instruction Manual Model #: 20-3031 and 20-3131 Literature #: 98-0919/02-07... - Page 3 Your CABELA’S VLR by BUSHNELL ® is a precision instrument designed to provide many years of enjoyment. This booklet will help you achieve optimum performance by explaining its adjustments and features as well as how to care for this precise laser rangefinding instrument. To ensure optimal performance and longevity, please read these instructions before using your Cabela’s VLR.
-
Page 4: Operational Summary
reflective properties of the particular target and the environmental conditions at the time the object is being distanced to. The color, surface finish, size and shape of the target all affect reflectivity and range. The brighter the color, the longer the range. Red is highly reflective, for example, and allows longer ranges than the color black, which is the least reflective color. - Page 5 LCD. To select between yards and meters, look through the monocular, depress the “mode” button (left side of the unit underneath the Cabela’s VLR by Bushnell logo) and hold it down for approximately 2 seconds. If you are changing from yards to meters, a change in unit of measure will be indicated by the illumination of the letter M for METER indicator while the YD for YARD indicator is turned off.
- Page 6 SCAN (LCD Indicator - “SCAN”): When the Power button is held down longer than 3 seconds, the unit transitions to SCAN mode. This mode allows the range to be continuously updated as long as the Power button remains depressed. The word “SCAN” will blink and appear in the left side of the LCD once this mode is activated.
- Page 7 SPECIFICATIONS OPTICAL DESIGN The CABELA’S VLR features a Perma Focus ® monocular optical system for viewing your target. A liquid crystal display (LCD) is mounted within the optical system and when activated, displays a reticle for targeting, yard / meter and mode designations, and low battery indicators. Inherent in the manufacturing process are small black spots that appear in the optical system.
- Page 8 CLEANING Gently blow away any dust or debris on the lenses (or use a soft lens brush). To remove dirt or fingerprints, clean with a soft cotton cloth, rubbing in a circular motion. Use of a coarse cloth or unnecessary rubbing may scratch the lens surface and eventually cause permanent damage.
- Page 9 If target range cannot be obtained: • Make sure LCD is illuminated. • Make sure that the power button is being depressed (as opposed to mode button). • Make sure that nothing, such as your hand or finger, is blocking the objective lenses (lenses closest to the target) that emit and receive the laser pulses.
- Page 10 FCC Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
