- Page 1 Operation Manual Model 600 Moisture Sensor Kit for Large Square Balers Forage Harvester 010-0600-OPR 10/14...
- Page 2 (intentionally blank)
-
Page 3: Table Of Contents
Harvest Tec Model 600 Operations Table of Contents PAGE Introduction System Requirements Safety Safety Decals Connecting Power and Communication Harness Operation of the ISOBUS Monitor Descriptions of Screens and Menus for the ISOBUS Monitor 7-13 Automatic Mode Manual Mode Diagnostics... -
Page 4: Introduction
System has been designed to plug directly into most tractors that have an ISOBUS Monitor. If you do not have one you may need to order the Touch Screen Display (TSD 030-5670A). The 600 Moisture Monitoring System offers these advantages;... -
Page 5: Safety
Safety Carefully read all the safety signs in this manual and on the applicator before use. Keep signs clean and visible. Replace missing or damaged safety signs. Replacement signs are available from your local authorized dealer. See your installation manual under the replacement parts section for the correct part numbers. -
Page 6: Connecting Power And Communication Harness
ISOBUS Monitor manual to verify how this upload is displayed. Once the upload has completed the operator can toggle between the tractor display and the Harvest Tec functions by pushing the Next Implement key. This key may have circling arrows or arrows forming a triangle. -
Page 7: Descriptions Of Screens And Menus For The Isobus Monitor
Description of Screens and Menus for ISOBUS Monitor This system is calibrated for use with Harvest Tec buffered propionic acid. The use of other products can cause application problems and damage to system components. It is designed to apply rates of 44 to 632 pounds of acid per hour and read moisture levels of 6 to 70 percent. -
Page 8: Automatic Mode
Screen Menus Use the below listed screen menus to navigate through all of the operation screens. Navigation through the screens is accomplished by using the touch screen of the controller and pressing. Automatic Mode:... -
Page 9: Manual Mode
Manual Mode: Diagnostics:... -
Page 10: Diagnostics
Diagnostics:... -
Page 11: Setup Mode
Setup Mode:... - Page 12 Setup Mode Continued:...
-
Page 13: Job Records
Job Records:... -
Page 14: Setting Up Application And Bale Weight Parameters
To change Rate of chemical application press any of the underlined numbers to the right of RATE. Remember level 1 must be lower than level 2 and level 2 must be lower than level 3. Harvest Tec products recommend rates of 4, 6, and 10 lbs/ton. These rates are preset from the factory. Press Back to return to previous screen. -
Page 15: Baling Rate Setup
Baling Rate Setup After pushing the SETUP MODE key in the MAIN MENU screen, the top screen should appear: 1. On this screen the operator will Select the BALING RATE SETUP key. 2. Select the number to the right of AVG Bale Weight (Lbs): to adjust the weight of your bales. The key pad shown will display. -
Page 16: Operating Instructions
Operating Instructions Automatic Mode will automatically apply product based on both hay moisture content sensed by the star wheels and the operator’s preset parameters. (See Setting Up System for Initial Use to change any of these settings). Manual Mode will apply preservative to the hay at a fixed rate regardless of the moisture content or baling rate. -
Page 17: Manual Mode
Manual Mode After pushing the MANUAL MODE key in the MAIN MENU screen, the following screen should appear: 1. Push the Pause key (1) to stop application while in operation. 2. Push the Override key (2) to turn on all three pumps at the same time for full output of the system. Use this mode when going through a short area of wet crop. -
Page 18: Diagnostics
Diagnostics After pressing the DIAGNOSTICS key in the MAIN MENU screen, the screen on the left should appear: 1. To set date and time select the Set Date/Time key. In the next screen enter the date (month, day, year format) followed by the time. When done select the ENTER key. NOTE: The clock uses military (or 24 hour) time. -
Page 19: Job Records
Job Records After pushing the JOB RECORDS key in the MAIN MENU screen, the upper left screen below should appear 1. Selecting New Job will save all the previous bale records and open the Field Name screen. 2. Use the key pad in the Field Name screen to enter up to an eight character field name. Use the asterisk key to move on to the next letter or number if they are identical. - Page 20 Job Records (continued) 1. Selecting the Download key will open the Download Job Records screen. This screen lets you select jobs to download onto a USB drive. To download insert a USB drive into the port on the Dual Channel Processor.
-
Page 21: Maintenance
Maintenance Dielectric Grease Connections: Disconnect all harnesses on the applicator, clean the connections, and repack with dielectric grease. Battery Connections: Follow the batteries safety warnings and clean the battery connections. If the connections cannot be cleaned, replace harness. Winter Storage Disconnect power from the Dual channel Processor (DCP). -
Page 22: 600 Series Harnesses/Wiring Installation And Diagram
The power harness must be connected to the battery! The unit will draw more amps than convenience outlets can handle. Any modifications of the power harness will void systems warranty. IF MODIFICATIONS ARE REQUIRED CONTACT HARVEST TEC FIRST! b. This unit will not function on positive ground tractors. -
Page 23: Pin Outs For Harnesses And Wiring Diagram
Pin Outs for Harnesses and Wiring Diagram Power/Comm Harness 006-6650TM at Hitch Pin 1 Red +12V Power to TSD Pin 2 Red +12V Power to DCP Pin 3 Orange Keyed Power Pin 4 Gray Shield Pin 5 Green HT Can Low Pin 6 Yellow HT Can Hi Pin 7 Orange... - Page 24 Main Power Connector on DCP Pin 1 Red +12V Power from tractor Pin 2 Black Ground from tractor Pin 3 Orange Keyed power Star Wheel and Bale Rate Sensor Connector on DCP Pin 1 Blue +12V Power Pin 2 Orange Ground Pin 3 Black Signal for sensor 1...
-
Page 25: Common Questions
1. How do I turn the system on/off? Turn the key in the tractor to the ON position. The ISOBUS Monitor will turn on, and the baler, on 600 working screen tabs, will be viewable. Turn the system off by turning the tractor key OFF. -
Page 26: Troubleshooting
5. Short in wire between star 5. Replace wire. wheels and DCP. 6. Check hay with hand tester 6. Contact Harvest Tec if conditions to verify. persist. Moisture readings erratic. 1. Test bales with hand tester to verify that DCP has more variation than hand tester. -
Page 27: Parts Breakdown
Parts Breakdown for Star Wheel Moisture Sensors Description Part# Description Part# Block cover 006-4641B Star wheel block 006-4641A Electronic swivel 006-4642A Star wheel sensor 030-4641C Swivel insert w/ Ref # 10 Twine guard-left 001-4645 Snap ring (per side) 006-4641K Twine guard-right (prox) 001-4644 Washer (per side) w/006-4641K... -
Page 28: Control Boxes And Wiring Harnesses
Parts Breakdown for 600 Series Control and Harnesses Dual Channel Processor (DCP) Ref Description Part Number Dust Plugs 006-5651PLUGS End of Bale Sensor 600 Series 006-7400 Hesston 4755, 4910 EOB Mount 001-4648H EOB Bracket CLAAS 3300 001-4648C Krone EOB Bracket... -
Page 29: Optional Touch Screen Display (Tsd)
Optional Touch Screen Display (TSD) Touch Screen Display 006-6670 Ram Mount 001-2012H Suction Cup Mount 001-2012SCM Complete Kit 030-5670A... -
Page 30: Large Square Template
Edge of baler chute 9” angle iron Cut here angle iron 5/8” 1/2” Edge of star wheelbase Notch for star wheel should line up with edge of notch 2” 3” Position of star wheel base Star wheel base holes 4 holes, 5/16” diameter... -
Page 31: Notes
WARRANTY AND LIABILITY AGREEMENT Harvest Tec, Inc. will repair or replace components that are found to be defective within 12 months from the date of manufacture. Under no circumstances does this warranty cover any components which in the opinion of Harvest Tec, Inc. have been subjected to negligent use, misuse, alteration, accident, or if repairs have been made with parts other than those manufactured and obtainable from Harvest Tec, Inc. - Page 32 HARVEST TEC, INC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
