Harvest TEC 600A Operation Manual

Moisture sensor kit for large square balers

Advertisement

Quick Links

Operation Manual
Model 600A
Moisture Sensor Kit for Large Square Balers
Forage Harvester
600A-16-OPR-Imp&Metric
5/18
1

Advertisement

Table of Contents
loading

Summary of Contents for Harvest TEC 600A

  • Page 1 Operation Manual Model 600A Moisture Sensor Kit for Large Square Balers Forage Harvester 600A-16-OPR-Imp&Metric 5/18...
  • Page 2 European Parliment and the Council of 17 May 2006 and other applicable European Directives including Directive 2004/108/EC on the Electromagnetic compatability. The application of preservatives for hay Harvest Tec system will be turned on after being installed on a farm press has been declard in conformity with the Machinery Directive.
  • Page 3: Table Of Contents

    600A Operations Manual Table of Contents PAGE Introduction System Requirements Safety Safety Decals Operation of the 600A Moisture Sensor Kit 5-12 Operations of the ISOBUS Monitor Baler Monitor Setup System Setup Adjust the Moisture Alarm Option To Turn OFF/ON All Alarms or Beeps...
  • Page 4: Introduction

    Harnesses, Bluetooth receiver and Miscellaneous Hardware. For your convenience a parts break down for the 600A Moisture Monitoring System is included in the back of this manual. If you do have questions please bring this manual into the dealership. They can assist you in ordering the correct replacement parts.
  • Page 5: Operation Of The 600A Moisture Sensor Kit

    Operation of 600A Moisture Sensor Kit Operation of the ISOBUS Monitor The ISOBUS Monitor utilizes a combination of soft keys, number menus, and the scroll wheel on the upper right side of the actual monitor to make selections. Selections are made by scrolling the Thumb Wheel and pressing in once the selection is highlighted.
  • Page 6: System Setup

    System Setup 1. To view moisture from the 600A Moisture Sensor begin setup at the main baler screen. Select the WRENCH icon (arrow A) which is the fourth icon down on the right side of the screen-the right selection menu.
  • Page 7 3. A similar screen will appear with a different menu options on the right side of the screen. Press the A B icon (arrow C) located at the top right of the selection menu. 4. The A B screen will appear. Next select the A B 2 (arrow D) icon which is the second from the top on the far right selection menu.
  • Page 8 5. The A B 2 screen will appear. The Harvest Tec On/Off selection icon can now be selected. To turn the Harvest Tec Moisture Sensor On (signified by a green check mark) or Off (signified by a red X) navigate to the box and select (arrow E) by pressing the Scroll Wheel. Once the Harvest Tec Moisture Sensor has been turned On/Off you can navigate back to the main baler work screen by pressing the BALER (arrow F) icon on the top right of the selection menu.
  • Page 9 7. Once the user has selected the container they would like to change, a drop down list (arrow H) will appear. The Moisture option (arrow I) should be at the bottom of the drop down selection list. 8. The Moisture container will have a red background until HayBoss G2 system is put in Manual Mode or Auto Mode.
  • Page 10: Adjust The Moisture Alarm

    Adjust the Moisture Alarm 1. From the main baler screen, select the third icon down the right selection menu that shows a diamond beside a baler (arrow K). 2. To adjust the moisture alarm set point select the box option to the right of the moisture droplets (arrow L) and adjust to the desired moisture limit.
  • Page 11: Option To Turn Off/On All Alarms Or Beeps

    Option to turn Off/On all Alarms or Beeps 1. From the main baler work screen select the third icon down the right selection menu that shows a diamond beside a baler (arrow N). 2. Select the fourth icon on the right selection menu showing a bugle beside an alarm icon (arrow O).
  • Page 12 3. The alarm screen should now be displayed. All alarms can be silenced before they are ever heard. This can be done by selecting the Peak Moisture icon (arrow P) and turning the alarm On/Off. To return to the baler work screen, press the baler icon located at the top right of the selection menu. If the moisture is higher than the alarm setting the moisture values will be displayed with a red background but there will be no audible alarm if this is turned off.
  • Page 13: Wiring Diagram

    The power harness must be connected to the battery! The unit will draw more amps than convenience outlets can handle. Any modifications of the power harness will void systems warranty. IF MODIFICATIONS ARE REQUIRED CONTACT HARVEST TEC FIRST! b. This unit will not function on positive ground tractors.
  • Page 14: Pin Outs

    Pin Outs Power/Comm Harness 006-6650TM(E) at Hitch Pin 1 Red +12V Power to TSD Pin 2 Red +12V Power to DCP Pin 3 Orange Keyed Power Pin 4 Gray Shield Pin 5 Green HT Can Low Pin 6 Yellow HT Can Hi Pin 7 Orange Can1 Hi Pin 8 Black...
  • Page 15 Pin Outs (continued) 006-6650VA to 006-6650LS2(E) Pin 1 Red Can Power Pin 2 Black Can Ground Pin 3 Yellow HT Can Hi Pin 4 Gray Shield 3 4 5 Pin 5 Green HT Can Low Pin 6 N/A Pin 7 N/A 006-6650VA Harness to Baler Plug Pin A N/A Pin B Red...
  • Page 16: Common Questions

    Common Questions 1. How do I turn the system on/off? To turn the system ON open the Hay App, then select the active system for the baler you are using. Press the Wake Up tab if the system was put into Standby mode when last used. If not in Standby mode, select Automatic or Manual mode to begin.
  • Page 17: Troubleshooting

    5. Short in wire between star 5. Replace wire. wheels and DCP. 6. Check hay with hand tester 6. Contact Harvest Tec if conditions to verify. persist. Moisture readings erratic. 1. Test bales with hand tester to verify that DCP has more variation than hand tester.
  • Page 18: Parts Breakdown

    Parts Breakdown Star Wheels and Bale Rate Sensors Ref Description Part# Description Part# Block cover 006-4641B Star wheel block 006-4641A Electronic swivel 006-4642A Star wheel sensor 030-4641C Swivel insert w/ Ref # 10 Twine guard-left for AGCO 001-4645H Snap ring (per side) 006-4641K AGCO 001-4644H Twine guard-right for...
  • Page 19: Controls And Harnesses

    Parts Breakdown for 600A Series Control and Harnesses Ref Description Part Number End Of Bale Sensor 006-7400 Terminating Connector w green cap 006-5650Z End of Bale Sensor Bracket 001-4648 DCP Shield/Cover 001-5650X DCP Main Control LS 600 AUTO 006-6671LS DCP Baler Harness 30 FT...
  • Page 20: Optional Ipad Mini Mounting Kit

    Optional iPad Mini Mounting Kit (030-2014MK) Description Part # Suction cup mount 001-2012SCM Ram mount 001-2012H iPad Mini spring load cradle (Mini 1,2,3) 001-2012SLC 16 gauge power wire 006-4723P Female spade connector Hardware Eye loop connector Hardware iPad Mini Charger 12V 001-2012P iPad Mini 4 case 001-2012C4...
  • Page 21: Optional Ipad Display Kit

    Optional iPad Display Kit (030-4670DK) Description Part # Ref Description Part # Suction cup mount 001-2012SCM iPad Mini Charger 12V 001-2012P Ram mount 001-2012H iPad Mini 4 case 001-2012C4 iPad Mini spring load 001-2012SLC iPad Mini 4 006-4670IP cradle (Mini 1,2,3) 16 gauge power wire 006-4723P 4 amp fuse...
  • Page 22: Notes

    Notes...
  • Page 23: Warranty

    Harvest Tec, Inc. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion.
  • Page 24 HARVEST TEC, INC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
