Bond PGF5820-2 Owner's Manual

Hide thumbs Also See for PGF5820-2:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

READ BEFORE USE!
WARNING
USE PROPANE GAS ONLY!
-Do not store or use gasoline or other
flammable vapors in the vicinity of this or any other
appliance.
- Service must be performed by a qualified installer, service
agency or the gas supplier.
WARNING
For use with cylinders marked PROPANE only.DO NOT
connect to a remote gas supply.
If the firebowl is stored indoors, detach and leave propane
cylinder outdoors.
Design certified under ANS Z21.97 • CSA 2.41-(2014)
Requirements for Outdoor Gas Fireplaces
OWNER'S MANUAL
Factory No.:
PGF5820-2
WARNING
For Outdoor Use Only! Use Propane Gas Only !
Propane cylinders sold separately.
Improper installation,
adjustment,alteration,service or maintenance can cause
injury or property damage. Read the owner's manual
thoroughly before installing or servicing this
equipment. If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
The propane cylinder must be disconnected
when this firebowl is not use.
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance
and immediately call your gas supplier or fire
department.
WARNING
This firebowl must be attended at all times!
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
1
Style No.: 6 8183
WARNING
WARNING
DANGER
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PGF5820-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Bond PGF5820-2

Summary of Contents for Bond PGF5820-2

  • Page 1 OWNER'S MANUAL Factory No.: PGF5820-2 Style No.: 6 8183 READ BEFORE USE! WARNING For Outdoor Use Only! Use Propane Gas Only ! Propane cylinders sold separately. WARNING Improper installation, adjustment,alteration,service or maintenance can cause injury or property damage. Read the owner's manual thoroughly before installing or servicing this equipment.
  • Page 2 DANGER Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. WARNING *Do not use this firebowl for cooking. *Do not burn any other materials than are supplied with and intended for use in this firebowl.
  • Page 3 The LP-gas supply cylinder must be disconnected when this appliance is not in use Only cylinder marked “propane” shall be used. Caution: Only use the pressure regulator and hose assembly supplied with this firebowl. Replacement pressure regulator and hose assemblies must be specified or supplied by BOND MANUFACTURING CO.
  • Page 4 WARNING ! * Do not light or use gas unit if lava rocks or pumice stone are wet. Ensure lava rocks or pumice stone are completely dry before igniting as intense heat could cause the rock to crack. * Lava Rocks or Pumice stone could hit somebody's face or eyes during initial start of this unit , so please keep away from the firebowl for the first 20 minutes after it has been ignited.

  • Page 5: Hardware Contents

    HARDWARE CONTENTS ASSEMBLY INSTRUCTIONS * Please keep these owner's manual for future reference. * Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 5 minutes Tools Required for Assembly (included): Wrench NOTE: You must follow all steps to properly assemble the firepit.
  • Page 6 2. From underside of lid (A), place spring washer (BB) and then flat washer (CC) onto threaded part of handle (D). Secure with M6 nut (DD), tightening with wrench (E). 3. Place pumice stones (C) into body (B). 4. This item requires a 20 lb. propane tank (not included) in order to operate correctly.
  • Page 7 5. Cover body (B) with lid (A). To lock in place, turn clockwise. To unlock, turn counterclockwise. OPERATING INSTRUCTIONS Perform leak test in a well-ventilated area outside and where no source of spark can occur. DO NOT cover firepit directly after flame is out. Wait 5 minutes for firepit to cool prior to placing lid on firepit. Connect tank cylinder to regulator.

  • Page 8: Routine Care

    ※Please contact the Manufacturer for information regarding replacement hoses, ignitors, lava rocks or pumice stone, etc. IF YOU HAVE QUESTIONS OR CONCERNS PLEASE CALL BOND TOLL FREE # 1-866-771-BOND(2663) OR TO BETTER EXPEDITE YOUR REQUEST FEEL FREE TO EMAIL US customer.service@bondmfg.com...
