DYNAMIC CONTROLLER DIAGNOSTIC FLASH CODES

The service indicator will flash error codes when the Dynamic controller detects an abnormal condition in the
electrical system. The service indicator will flash a number of times quickly, then pause, then flash again. The
service indicator will continue to flash the error codes until the problem is fixed.
NOTE: When the service indicator flashes an error, the battery condition meter LEDs will also flash an inhibit.
ERROR
PROBABLE CAUSE
CODE
Possible stall timeout or user error
1
Battery fault
2
Left Motor Fault
3
Right Motor Fault
4
Left Park Brake Fault
5
Right Park Brake Fault
6
Dynamic Controller Module Fault
7
Dynamic Controller Power Module Fault
8
Dynamic Controller Communications Fault Check the communications connections and wiring.
9
Unknown Fault
10
Incompatible Controller Fault
11
What if the left red battery condition meter LED on the Dynamic is flashing?
This indicates that the battery voltage is very low and the batteries should be charged immediately.
What if the power chair does not drive and the battery condition meter LEDs are scrolling from right to left?
This indicates that the Dynamic controller is in lock mode. To unlock, press the horn button twice.
What if the battery condition meter LEDs are scrolling from left to right, alternating with a steady display?
This indicates that the Dynamic controller is in programming, inhibit, or charging mode. When the joystick is
moved, the speed setting indicator will also flash.
What if the power chair will not drive and all battery condition meter LEDs are flashing rapidy nonstop?
The Dynamic controller has detected an Out of Neutral At Power Up (OONAPU) condition. This means that the
joystick was not in the neutral (center) position when the controller was turned on. To clear the fault, allow the
joystick to return to the neutral (center) position.
4
B T
ASIC ROUBLESHOOTING
www.pridemobility.com
I : J
NSTRUCTIONS AZZY
POSSIBLE SOLUTION
Release the joystick.
Check the batteries and cables. Try to charge the batteries.
The batteries may need to be replaced.
Check the left motor, connections, and cabling.
Check the right motor, connections, and cabling.
Check the left park brake, connections, and cabling.
Check the right park brake, connections, and cabling.
Check the communications connections and wiring.
Check the communications connections and wiring.
Contact your authorized Pride Provider.
Contact your authorized Pride Provider.
