CONNECTOR PIN ASSIGNMENT
PIN NO.
1.
2.
3.
4.
5.
6.
7.
8.
15-Pin Color Display Signal Cable
DESCRIPTION
Red
Green
Blue
Monitor Ground
DDC-return
R-Ground
G-Ground
B-Ground
EN- 11
PIN NO.
DESCRIPTION
9.
10.
Logic Ground
11.
Monitor Ground
12.
DDC-Serial Data
13.
H-Sync
14.
V-Sync
15.
DDC-Serial Clock
T230H
+5V
