Owner's Manual & Assembly Instructions
AJ01
Model No.
722920817
Storage Area:
54 Sq. Ft. 345 Cu. Ft.
5,0 m
2
BUILDING DIMENSIONS
*Approx.
Size
10' x 6'
121" x 68 3/4"
3,0m x 1,7m
307,3cm x 174,6cm
ED106
SBVD106
VD106
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
9,8 m
3
* Size rounded o to the nearest foot
Exterior Dimensions
Base
(Roof Edge to Roof Edge)
Size
Width
123 1/4"
313,1cm
181,0cm
ED106L
WR106
B
VD106EU
A
VDGY106EU
Depth
Height
Width
71 1/4"
82 1/8"
118 1/4"
208,6cm
300,4cm
ED106BS
WR106EU
VDGY106
A
697.68617
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Depth
Height
66"
80 7/8"
167,6cm
205,4cm
A
Door
Opening
Width
Height
55 1/2"
69 1/4"
141,0cm 175,9cm

Advertisement

loading

Related Manuals for Arrow Storage Products ED106

Summary of Contents for Arrow Storage Products ED106

  • Page 1 Owner's Manual & Assembly Instructions AJ01 Model No. ED106 ED106L ED106BS WR106 WR106EU SBVD106 VD106 VD106EU VDGY106 VDGY106EU 697.68617 Missing Parts, Questions on Assembly? Call: 1-800-851-1085 or assist@arrowsheds.com Do not return to dealer, they are not equipped to handle your requests.
  • Page 2 GB: Assembly manual in additional languages available online. Scan QR code below to access. FR: Manuel de montage disponible en ligne dans d’autres langues. Pour y accéder, scannez le code QR ci-dessous. SP: Manual de montaje en idiomas adicionales disponible online. Escanee el código QR a continuación para acceder.
  • Page 3 BEFORE YOU BEGIN..Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.

  • Page 4: Tools And Materials

    PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 5 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
  • Page 6 CARE & MAINTENANCE..Finish: For long lasting nish, periodically clean and wax the exterior surface. Touch-up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
  • Page 7 ACCESSORIES..FLOOR FRAME KITS ROOF STRENGTHENING (heavy snow load) KITS Extra roof beams and gable braces designed for added protection against heavy snow accumulation. Increases the strength of your roof. BEFORE AFTER ANCHOR KITS Model No. AK4 MODELS FB47410, FB5465, FB106-A Anchor Kit contains heavy-duty steel FB109-A and FB1014-A augers, 60' (18 m) of steel cable and...
  • Page 8 ORDERING ACCESSORIES..02/13 We recommend that you purchase accessory items from your local storage building dealer whenever possible; however, because the full line of accessories is not always available from all dealers, Arrow is o ering them to you on a direct basis. There are two ways to order Arrow Storage Building Accessories: Option 1 Option 2...
  • Page 9 Base The Base For Your Building No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an e ective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).
  • Page 10 Anchoring Anchoring Down The Building It is important that the entire oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base.
  • Page 11 Hardware PN11 Remove from bag of screws and save for the last step 65900A #10Bx1/2" (13 mm) 65923 65004 65103 Black Screw (8) #8-32x3/8" (10 mm) #8Ax5/16" (8 mm) #8-32 Hex Nut (89) (Packed with Screws) Bolt (89) Screw (284) 66646 66045 Washer (166)

  • Page 12: Parts List

    Parts List AJ12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 8934 Ramp 9367 Front Floor Frame 8936 Rear Floor Frame 9338 Right Rear Wall Angle 9366 Door Track 6403 Door Track Splice 9339 Left Rear Wall Angle 6001 Left Gable 6000...
  • Page 13 Assembly by Key No. AJ13...
  • Page 14 Step 1 8934 Ramp (1) Parts Needed For 9367 Front Floor Frame (2) Floor Frame Assemblies 8936 Rear Floor Frame (2) The front oor frame is made up of three pieces. The rear oor frame is 9367 made up of two pieces. The holes in these pieces will align when the pieces are positioned with correct 8934...

  • Page 15: Frame Assembly

    Step 2 Parts Needed For 9338 Right Rear Wall Angle (1) Frame Assembly 9339 Left Rear Wall Angle (1) The main frame pieces reinforce the walls. This piece will later be installed at the top edge of the rear wall. Pro- ceed as follows: Overlap the right and left rear wall angle pieces as shown in the...
  • Page 16 Step 3 Parts Needed For 8474 Roof Beam (1) Roof Beam Assembly 8476 Side Wall Angle (1) The roof beams join the two gables and support the roof panels. The main roof beam is made up of two pieces fastened together. Place the side wall angle, back- to-back, with a roof beam and fasten together using ten screws.
  • Page 17 Step 4 Parts Needed For 6403 Door Track Splice (1) Door Track Assembly 9366 Door Track (2) NOTE: The door track assembly supports the Door Track Splice (painted part) sliding doors and reinforces the front wall. It is made up of three pieces. 6403 Using the door track splice, (painted), join the door track...
  • Page 18 Step 5 Parts Needed For Front Floor Assembly (1) 8946 Side Floor Frame (2) Floor Frame Rear Floor Assembly (1) RIGHT REAR Assemble the four corners of 8946 the oor frame using two screws at each corner as shown. At the front STEP corners fasten bolts through from 8946...
  • Page 19 5288 Corner Post (4) Step 6 Parts Needed For Door Track Assembly (1) Posts/Top Frames Rear Wall Angle Assembly (1) 9342 Side Wall Angle (2) NOTE The remainder of the building assembly requires many hours and more than one person. Do not continue beyond this point if you do not have enough time to complete the assembly today.
  • Page 20 Step 7 Parts Needed For 5287 Splice Post (1) Splice Post/Door Jamb 7311 Door Jamb (2) STEP The door jambs reinforce the door opening and provide an attractive 5287 trim. The splice post supports the rear wall. Position splice post at the center of the rear wall and fasten using 4 bolts and nuts into rear wall angle and 2 screws into rear oor frame.
  • Page 21 Step 8 Parts Needed For 9344 Siding Stud (6) Studs/Front Channel 9365 Front Wall Channel (2) The studs provide a surface for at- taching the siding panels. Following dimensions, measuring from the ends of angles, place a stud between each corner and splice post at the rear of building and 2 studs between corner posts at the sides.

  • Page 22: Side Siding

    Step 9 Parts Needed For 8719 Side Siding (6) Side Siding Each screw in the wall requires a washer. CORRECT INCORRECT STEP Slide side siding into channels of corner posts, flat edge upward, bottom edge down resting on oor STEP frame.
  • Page 23 Step 10 Parts Needed For 8736 Rear Siding (6) Rear/Front Siding 8737 Front Siding (6) STEP STEP Slide rear siding into channel of corner and splice posts fastening to Fasten Top Center of rear frame as shown in previous step Last Siding to Stud 8736 Install rear siding to complete...
  • Page 24 Step 11 Parts Needed For 6000 Right Gable (2) 6001 Left Gable (2) Gable Assemblies 5971 Roof Beam Bracket (4) Y24et ctr STEP Edge Trim (Plastic Piece) The gables go on top of the front and rear walls to support the roof beams. NOTE The gables are packed nested together and might be mistaken...
  • Page 25 Step 12 Left Gable Assemblies (2) Parts Needed For Right Gable Assemblies (2) Gables/Braces 6635 Gable Brace (2) X25 ctr (20) Lift and fasten a right and left gable, under angle at corner, to the rear wall angle with screws. Hint: On the rear gable, use a bolt and nut at the overlapping rear wall angle.
  • Page 26 Step 13 Parts Needed For Main Roof Beam (1) Roof Beams 8474 Roof Beam (2) Fasten the main roof beam to STEP the gable brace of the front gable. Fasten the other end of the main 8474 Roof Beam roof beam to the gable brace of the rear gable.
  • Page 27 Step 14 Parts Needed For 8468 Right Roof Panel (1) Right Roof Panel X27et STEP Installing the roof panels is best done with a step ladder. Begin installing roof panels at the back right corner 8468 8469 of the building. Each screw and bolt in the roof requires a washer.

  • Page 28: Roof Assembly

    Step 15 8468 Right Roof Panel (1) Parts Needed For 8469 Left Roof Panel (2) Roof Assembly 6529 Roof Panel (4) 8469 Left Roof Panel STEP Weather Stripping STEP Tape Roll Install a left roof panel at the left rear and right front corner of the roof. Install a right roof panel at the left 8468 Right Roof Panel...
  • Page 29 Step 16 Parts Needed For 8461 Ridge Cap (1) Ridge Cap/Roof Trim 8482 Side Roof Trim (2) Install the ridge cap on the com- STEP 8461 pleted roof section using bolts. Do not fasten the ends of the ridge cap until instructed to do so.

  • Page 30: Door Assembly

    Step 17 3719 Door Handle Brace (2) Parts Needed For 10472 Right and Left Doors (2) Door Assembly 10497 Horizontal Door Brace (4) BB30 6301 Vertical Door Brace (2) The steps on this page tell how to assemble the right door. You will per- form exactly the same procedures for the left door.
  • Page 31 Step 18 Parts Needed For Right Door Assembly (1) Door Installation & Adjustment Left Door Assembly (1) Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the building) behind door jamb into the STEP STEP...
  • Page 32 ED106 ED106L ED106BS SBVD106 WR106 WR106EU VD106 VD106EU VDGY106 VDGY106EU 697.68617 AJ32 Anchoring and Floor Frame Anchoring Anchor your building at this time. Floor Frame If you have purchased a Floor Frame Kit you need to install it at this time.
