Hydronic Corporation
Air Driven Hydraulic Pumps and Intensifiers
P826 Installation, Use and Maintenance Manual
Contents
Introduction, Guarantee and Identification Plate
Description, Start Up Procedures
Description of Working Parts, Storage and Disposal
Fault Finding, Maintenance and Weights
Spare Parts
Hydronic Corporation, 2034 Fruit St, Algonac, MI 48001 United States of America
℡(810) 794 4935
www.hydroniccorp.com
Advertisement
Related Manuals for Hydronic P826
Summary of Contents for Hydronic P826
- Page 1 Contents Introduction, Guarantee and Identification Plate Description, Start Up Procedures Description of Working Parts, Storage and Disposal Fault Finding, Maintenance and Weights Spare Parts Hydronic Corporation, 2034 Fruit St, Algonac, MI 48001 United States of America ℡(810) 794 4935 www.hydroniccorp.com...
- Page 2 The guarantee cannot cover pumps that may have been tampered with. Defective goods must be sent to Hydronic Corporation at Farmington Hills or to the distributor covering the area, freight pre-paid in either case. Any pump returned to us must be accompanied by a full written description of such faults or defects as have been discovered.
- Page 3 3/8” bore for the suction line. Application Hydronic air driven hydraulic pumps are designed for operating oil hydraulic circuits and to cover the widest range of requirements to the best advantage. The pump itself operates quite simply, using a well-known pressure intensification principle.
- Page 4 Hydronic Air Driven Pumps 826 Installation, Use and Maintenance Booklet 8-26-14 Storage If the pump is to be kept out of use for a long period, clean the pump in general and drain the oil from the tank. Cover the pump and store it in a dry, well-protected place.
- Page 5 Hydronic Air Driven Pumps 826 Installation, Use and Maintenance Booklet 8-26-14 Starting - Up Oil pressure can be determined by regulation of the inlet compressed air pressure and bearing in mind the multiplication ratio pre-selected for the pump itself. The models are:...
- Page 6 In case of damage or if in doubt, do not use the pump and contact Hydronic Corporation or your distributor. The packaging [plastic bags, expanded polystyrene, nails, screws, wood, etc.] must not be left within reach of children since they are potential source of danger.
- Page 7 Hydronic Air Driven Pumps 826 Installation, Use and Maintenance Booklet 8-26-14 Gross weight P826 Basic pump of any ratio 27.1 lbs., 12.3 kgs. Contents of the package The packaging will always contain the following: 1 x air driven hydraulic pump...
- Page 8 Hydronic Air Driven Pumps 826 Installation, Use and Maintenance Booklet 8-26-14 Item Code Description 3.094.0208 Screw 5.086.0006 Head 3.051.0075 O-Ring 3.051.0076 Seal Ring 3.045.0204 Self-Locking Nut 5.034.0014 Piston 5.018.0030 Jacket 5.068.0193 Piston 5.068.0116 Piston 5.068.0115 Piston 5.068.0114 Piston 5.068.0113 Piston 3.051.0083...
- Page 9 Hydronic Air Driven Pumps 826 Installation, Use and Maintenance Booklet 8-26-14 Old Air Valve Item Code Description 3.094.0206 Screw 3.072.0102 Washer 5.027.0001 Cover 3.051.0080 O-Ring 5.008.0013 Disk 3.051.0081 O-Ring 7.078.0118 Distributor Pivot + Bushing 5.028.0026 Valve Body 3.051.0082 O-Ring 3.051.0002 O-Ring 3.072.0103...
