- Page 1 IDD-213W User Manual (Rev. 1.0) Sinocastel Co., Ltd. August, 2017...
-
Page 2: Table Of Contents
IDD-213W User Manual Contents 1. Introduction ..................................4 2. Specifications ................................... 5 2.1 External Interface ..............................5 2.2 Status Indicator ............................... 6 2.3 Technical Parameters ............................7 3. Device Configuration ..............................9 3.1 PC Tool ..................................9 3.2 SMS Instructions ..............................9 4. - Page 3 IDD-213W User Manual 5.17 Google Map Link ............................... 20 5.18 Remote Configuration ............................ 21 5.19 SMS Configuration ............................21 5.20 PC Tool Configuration ............................. 21 6. Disclaimer ..................................22 7. Warranty ..................................23 8. Statement ..................................24...
- Page 4 IDD-213W User Manual Regulatory Compliance FCC Regulations This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
-
Page 5: Introduction
IDD-213W User Manual 1. Introduction IDD-213W is an intelligent on-board diagnostic device with OBD II and SAE J1939/J1708 (Heavy duty) compliant, it features plug-and-play technology, could read diagnostic info from vehicle ECU and capture location data with built-in GPS, then send them to backend server for real-time remote diagnostic and tracking purpose. -
Page 6: Specifications
IDD-213W User Manual 2. Specifications 2.1 External Interface Product appearance as follows： 1. Standard OBD Connector Connect to the 16 pin on-board Diagnostic Link Connector (DLC). 2. Micro USB Interface Connect to PC through USB configuration cable. 3. SIM Card slot... -
Page 7: Status Indicator
IDD-213W User Manual 2.2 Status Indicator Indicator Color Status Blinking (on 0.5s, off 0.5s) - Trying to access OBD system or power off Power/OBD Solid on - Successful OBD communication Solid off - Tracker mode or in sleep Fast blinking (on 0.5s, off 0.5s) - No SIM card or network searching Slow blinking (on 0.5s, off 2.5s) - Registered network... -
Page 8: Technical Parameters
IDD-213W User Manual 2.3 Technical Parameters Dimension 64mm (L) x mm (W) x 28mm (H) Mechanical Weight OBD interface: 16 pin standard OBD II Interface Configuration interface: Micro USB SIM card interface: Push-Push Type Storage 2MB FLASH, can store up to 24000 GPS data... - Page 9 IDD-213W User Manual -109dBm@GSM 850/900MHz -108dBm@GSM 1800/1900MHz Output power: Class 4 (2W, 33dBm)@GSM 850/900MHz Class 1 (1W, 30dBm)@GSM 1800/1900MHz Class 3 (0.25W, 24dBm)@UMTS Certification: CE, GCF, FCC, PTCRB, IC, AT&T LED Indicator OBD/Cellular/GPS Buzzer System status/Alarm indication Cellular Antenna Built-in...
-
Page 10: Device Configuration
IDD-213W User Manual 3. Device Configuration 3.1 PC Tool Download USB driver and PC Tool at http://www.sinocastel.com/Support/. Install the USB driver and PC Tool on your PC. Connect device to PC through USB configuration cable, open the OBD PC Tool, click on “Help->User manual”... - Page 11 IDD-213W User Manual Send SMS *SecretKey#position#*, device will reply *position#http://maps.google.com /?q=latitude,longitude*. e.g.: *123456#position#*http://maps.google.com/?q=22.536934,114.021425* 3 3 . . 2 2 . . 6 6 S S e e t t w w o o r r k k i i n n g g m m o o d d e e...
-
Page 12: Installation Instruction
IDD-213W User Manual 4 4 . . I I n n s s t t a a l l l l a a t t i i o o n n I I n n s s t t r r u u c c t t i i o o n n 4 4 . -
Page 13: Obd Port
IDD-213W User Manual 4 4 . . 2 2 O O B B D D P P o o r r t t In general, the OBD port is located in the driver or passenger cabin, from the edge of dashboard on driver side to the border of 300mm. -
Page 14: Device Installation
IDD-213W User Manual 4 4 . . 3 3 D D e e v v i i c c e e I I n n s s t t a a l l l l a a t t i i o o n n Before installing the device, please make sure device has been configured with necessary parameters including network parameters and working mode. - Page 15 IDD-213W User Manual Some heavy duties may need 9-Pin or 6-Pin deutsch wiring harness. For vehicles do not have an OBD port, please use power cable to connect vehicle battery and configure the device with tracker mode. Start engine, then device starts OBD communication, acquiring GPS info and Cellular network connection.
- Page 16 IDD-213W User Manual mode. After auto scanning period device will not change working mode anymore even it is re-plugged, unless working mode is re-configured with PC Tool, via SMS, or from server. If tracker mode is pre-configured device will not scan OBD protocol and keep working with tracker mode unless working mode is re-configured.
-
Page 18: Functions
IDD-213W User Manual 5 5 . . F F u u n n c c t t i i o o n n s s 5 5 . . 1 1 O O B B D D P P r r o o t t o o c c o o l l s s Device supports all legislated OBD II protocols, it is also SAE J1939 and SAE J1708 compliant. -
Page 19: Regular G-Sensor Data Reporting
IDD-213W User Manual The suggested minimal interval for GPS report is 10s. For example, if only sampled by time interval is enabled, then the settings might be 10s of sample rate and 1 group of GPS data per message, or 5s of sample rate and 2 groups of GPS data per message. -
Page 20: Gps Data Reporting In Sleep Mode
IDD-213W User Manual 5 5 . . 8 8 G G P P S S D D a a t t a a R R e e p p o o r r t t i i n n g g i i n n S S l l e e e e p p M M o o d d e e Device reports GPS data according to configured time interval during sleep. -
Page 21: Working Mode
IDD-213W User Manual Plug indication Unplug notification Default thresholds for alarms: High RPM: 4500r/min Speeding: 120km/h Low battery voltage: 10.5V High engine coolant temperature: 98 Hard acceleration: 0.4g Hard brake: 0.6g Excessive engine idle time: 15min Fatigue driving: 240min 5 5 . . 1 1 4 4 W W o o r r k k i i n n g g M M o o d d e e Device supports 3 types of working mode: Passenger car, Heavy duty and Tracker mode. - Page 22 IDD-213W User Manual Latitude and longitude in location SMS can be directly linked to Google map. 5 5 . . 1 1 8 8 R R e e m m o o t t e e C C o o n n f f i i g g u u r r a a t t i i o o n n Users can configure device or update firmware through website: http://www.livetelematics.com.
- Page 23 The device is compatible with OBD II standard, it is also SAE J1939 and J1708 compliant. While some vehicles are not following those standards, therefore Sinocastel can not guarantee the OBD performance of the device with every vehicle. The GPS function may be affected in electromagnetic shielding area or bunker place.
- Page 24 If product got quality problem within the warranty period, please bring the product together with a valid warranty card and purchase invoice to the dealer for checking. Please do not disassemble this product, this may result in damage, Sinocastel will not be responsible for those problem.
- Page 25 Without written permission from Sinocastel, it is prohibited reproduce, transmit, distribute or save part or all of the contents of this document in any form. Sinocastel reserves the rights to modify or improve these products without any prior notification. Sinocastel reserves the rights to change or cancel the content of this document without any prior notification.
