IDD-212B User Manual
(Rev. 2.1)
Sinocastel Co., Ltd
November, 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDD-212B and is the answer not in the manual?

Questions and answers

Related Manuals for SinoCastel IDD-212B

Summary of Contents for SinoCastel IDD-212B

  • Page 1 IDD-212B User Manual (Rev. 2.1) Sinocastel Co., Ltd November, 2013...

  • Page 2: Table Of Contents

    IDD-212B User Manual Contents 1. Introduction ............................ 2 2. Specifications ..........................3 2.1 External Interface ..........................3 2.2 Status Indicator ............................. 3 2.3 Technical Parameters ..........................4 3. Device Configuration ........................5 3.1 PC Tool ..............................5 4. Installation Instruction ........................6 4.1 OBD Port ..............................

  • Page 3: Introduction

    IDD-212B User Manual 1. Introduction IDD-212B is an intelligent on-board diagnostic box based on OBD II/EOBD standard with Bluetooth module, it could read various kinds of data including diagnostic info, mileage, fuel consumption and driving behavior, and real time display on Android/iOS/WinCE PND/CPND/Smart phone via Bluetooth.

  • Page 4: Specifications

    IDD-212B User Manual 2. Specifications 2.1 External Interface Product appearance as follows： Standard OBD Connector It is used to connect to the 16 pin on-board Diagnostic Link Connector (DLC). The vehicle OBD system is able to communicate with an external device which has the same protocol via this connector.

  • Page 5: Technical Parameters

    IDD-212B User Manual Blinking – Trying to communicate with on-board system OBD LED Green Solid on – Successful OBD communication Solid off – No OBD communication Blinking - GPS signal is good G-Mouse Green Solid on - Searching for GPS signal Solid off –...

  • Page 6: Device Configuration

    5%～95%（no frog） 3. Device Configuration 3.1 PC Tool Download USB driver and PC Tool at http://www.sinocastel.com/en/Downloads/. Install the USB driver and PC Tool on your PC. Connect device to PC through USB configuration cable, open the OBD PC Tool, configure the...

  • Page 7: Installation Instruction

    IDD-212B User Manual 4. Installation Instruction 4.1 OBD Port In general, the OBD port is located in the driver or passenger cabin, from the edge of dashboard on driver side to the border of 300mm. It is easy to touch by sitting in the driver's seat;...

  • Page 8: Device Installation

    IDD-212B User Manual 4.2 Device Installation Before installing the device, please make sure device has been configured with necessary parameters including network parameters and other parameters. Park the car and make sure engine is off, connect the G-Mouse to the device. Fix the G-Mouse above the dashboard horizontally;...
  • Page 9 IDD-212B User Manual Before login “VRM Coach”, need to disconnect other devices via Bluetooth connection and pair with IDD-212B. Login “VRM Coach” after IDD-212B is connected via Bluetooth:...
  • Page 10 IDD-212B User Manual...
  • Page 11 IDD-212B User Manual Input User name and password, it will show below main interface:...

  • Page 12: Initialization

    IDD-212B User Manual 4.4 Initialization...
  • Page 13 IDD-212B User Manual OBD will be initialized automatically when it connects to “VRM Coach” the first time It will load history data first if the device stored some history data:...
  • Page 14 IDD-212B User Manual Start to upload the new data after history data uploaded:...
  • Page 15 IDD-212B User Manual We advise you to drive the car for at least 10 minutes with the first installation.

  • Page 16: Functions

    IDD-212B User Manual 5. Functions 5.1 OBD Protocols The device supports all the OBD II standards below: Ø J1850-PWM Ø J1850-VPW Ø ISO 9141-2 Ø ISO 14230-4 (KWP2000) Ø ISO15765-4(CAN) 5.2 Location Inquiry Upon receiving location inquiry command from server or via SMS, device reports GPS data immediately.

  • Page 17: Data Storage/Supplementary Report In Dead Zones

    IDD-212B User Manual The device is able to read vehicle pending DTCs and stored DTCs, freeze frame data and a variety of diagnostic data. The backend server analyzes and displays the DTCs for users on time to avoid high repairing cost.

  • Page 18: Pc Tool Configuration

    IDD-212B User Manual Users can configure device via VRM Coach 5.14 PC Tool Configuration Users can configure device or update firmware through PC Tool.

  • Page 19: Disclaimer

    IDD-212B User Manual 6. Disclaimer This user manual only applies to IDD-212B device. This product only applies to the vehicles with OBD II/EOBD equipped. This product strictly follows the standard of ISO15031, it shall not cause any harm or affects on vehicles, if there is an exception, please remove the device immediately.

  • Page 20: Warranty

    IDD-212B User Manual 7. Warranty If product got quality problem within the warranty period, please bring the product together with a valid warranty card and purchase invoice to the dealer for checking. Please do not disassemble this product, this may result in damage, CASTEL will not be responsible for those problem.

  • Page 21: Statement

    IDD-212B User Manual 8. Statement Without written permission from CASTEL, it is prohibited reproduce, transmit, distribute or save part or all of the contents of this document in any form. Castel reserves the rights to modify or improve these products without any prior notification.
