ST62GP-EMU2 Emulator User Manual
2
GETTING STARTED
2.1
Delivery checklist
The following items are packed with the ST62GP-EMU2 (refer to
•
ST62GP-EMU2 box with two flat cables for connecting a probe.
•
One DB324/DIP probe board for use with ST6230, ST6218 and ST6228 target
devices.
•
One DB324/SDIP42 probe board for use with the ST6232 target device.
•
One DB448 probe board for use with ST620x, ST621x and ST622x target
devices.
•
One DB449 probe board for use with 5x and 6x devices, including:
-
16-pin probe with 3 different male-male interfaces, depending on the target
device.
-
20-pin probe with 3 different male-male interfaces, depending on the target
device.
-
28-pin probe with 3 different male-male interfaces, depending on the target
device.
A duplicate set of these interfaces is provided in case of damage.
Caution:
Take precautions against electrostatic discharge (ESD) before unpacking the emulator probe
boards. These boards must only be handled in a static-safe area.
•
Three probe adapters—DIP16, DIP20 and DIP28—to be soldered to a
footprint.
•
Three SO adapters—SO16, SO20 and SO28.
Note:
If the probe boards are already assembled with SO adapters, refer to
how to use the DIP connectors, if required.
•
One parallel interface cable (Ref.: DB25M/DB25M).
•
One power adapter.
•
One power cable.
•
Two ferrites to be clipped over the flat cables (for EMC compliance).
•
Analyser probes.
•
A CD-ROM, containing the WGDB6 debugger software. (Not shown).
•
This manual. (Not shown).
2 - Getting Started
Figure 1
):
Figure 3
on page 12 for
