aquanique QFP900 Instruction Sheet

Pressurized filter up to 900 gallons

Advertisement

REMINDER
CALL 1-888-314-2588
BEFORE RETURNING TO STORE.

PACKAGE CONTENTS

Part
A
B
C
D
E
F
G
H
I
Bio media balls
J
K
L

PREPARATION

Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or
operate the product. Contact customer service for replacement parts.
Estimated Assembly Time: 20 minutes
Tools required for assembly:
Pressurized Filter
Up to 900 gallons
Description
Tank
Cover
Lid
O-ring
Adapter
Gasket
Locking ring
Tube
Small filter
Coarse filter
Fine filter
hacksaw.
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-888-341-2588, 8 a.m.-6 p.m., EST, Monday-Friday,
Quantity
1
C
1
1
1
2
B
2
2
2
12
1
1
A
1
D
ITEM # QFP900
I
H
E
F
G
J
K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QFP900 and is the answer not in the manual?

Questions and answers

Summary of Contents for aquanique QFP900

  • Page 1 Pressurized Filter Up to 900 gallons ITEM # QFP900 Questions, problems, missing parts? Before returning REMINDER to your retailer, call our customer service department at CALL 1-888-314-2588 1-888-341-2588, 8 a.m.-6 p.m., EST, Monday-Friday, BEFORE RETURNING TO STORE. PACKAGE CONTENTS Part...
  • Page 2 ASSEMBLY INSTRUCTIONS 1. Assemble the tube, gasket and adapter. Insert the adapter and gasket into the outlet of the tank (lower hole). Fix it in place with the locking ring. Fig. 1 Gasket Tube Adapter Locking ring Fig. 1 2. Place the bio balls into the bottom of the tank. Fig. 2 Bio balls Fig.
  • Page 3 4. Insert the adapter and gasket into the inlet of the tank (upper Locking hole). Fix it in place with the locking ring. Fig. 4 ring Gasket Adapter Fig. 4 5. Turn over the cover and locate the groove. Place the o-ring into the groove.
  • Page 4 7. Screw the lid onto the top of the tank. Make sure that it is secure, or the filter will leak. Fig. 7 Tank Fig. 7 8. Connect a length of tube from the outlet of a pump to the inlet of the filter (upper hole).
  • Page 5 CARE AND MAINTENANCE • Occasional cleaning of the filter pads will be necessary to ensure the proper functioning of the system. The top filter pad is a coarse pad (black) and will catch larger particles. The bottom filter pad (blue) is a fine pad designed to trap smaller debris. Both pads should be removed and washed with clean water when they are visibly soiled.
  • Page 6 LIMITED WARRANTY All pumps and electrical products are warranted to the user against defective material and workmanship, under normal working conditions. This warranty period begins on the date of purchase by the original purchaser. Unless otherwise specified all pond boss® electrical products are warranted to the user against defective material and workmanship, under normal working conditions for 1 year from the date of purchase.
