REMINDER
CALL 1-888-314-2588
BEFORE RETURNING TO STORE.
PACKAGE CONTENTS
Part
A
B
Filter box bottom
C
Coarse filter pad
D
E
Bio media balls
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or
operate the product. Contact customer service for replacement parts.
•
Estimated Assembly Time: 15 minutes
•
No tools required for assembly.
PRODUCT DESCRIPTION
The QFUPFB is a general purpose, mechanical / biological filter system. It is designed to filter the water
and promote healthy bacteria that will provide a balanced environment in your pond. This filter is designed
to work with a water pump that can circulate a minimum of 200 gallons per hour. As a pre-filter, the
QFUPFB reduces pond debris and particulate before they enter the pump and other pond accessories.
This pre-filtration reduces the clogging of your pump and accessories and minimizes the need for cleaning.
ASSEMBLY INSTRUCTIONS
1. Place your pump inside the filter box, close to the center. Make
sure that the outlet points up. Route the cord through the hole
in the top corner of the filter box bottom. Fig. 1
NOTE: Pump is NOT INCLUDED. This filter is compatible
with pump models QFP320, QFP525, QPP225
QPP350 and QPP575.
Mechanical Filter Box
Up to 500 gallons
Description
Filter box top
Fine filter pad
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-888-314-2588, 8 a.m.-6 p.m., EST, Monday-Friday. Or
visit our website www.aquanique.com.
Quantity
1
A
1
1
1
10
B
ITEM #QFUPFB
C
D
E
Pump
Fig. 1
Advertisement
Table of Contents
Related Manuals for aquanique QFUPFB
Summary of Contents for aquanique QFUPFB
- Page 1 No tools required for assembly. PRODUCT DESCRIPTION The QFUPFB is a general purpose, mechanical / biological filter system. It is designed to filter the water and promote healthy bacteria that will provide a balanced environment in your pond. This filter is designed to work with a water pump that can circulate a minimum of 200 gallons per hour.
- Page 2 2. Place the bio-balls around the pump. Fig. 2 Bio balls Pump Fig. 2 3. Connect the extension tube to the outlet of the pump using the adapter (adapter is part of fountain head kit). Fig. 3 Extension tube NOTE: Fountain head kit (item #QNKL) is NOT INCLUDED, and is not required for operation.
- Page 3 5. Connect the two extension tubes with the coupler. Fig. 5 Extension tube NOTE: Extension tubes and coupler are NOT INCLUDED. Coupler Extension tube Fig. 5 6. Place the filter box top over the filter box bottom and connect the fountain head to the top extension tube. Fig. 6 Fountain head NOTE: Fountain head kit is NOT INCLUDED.
- Page 4 9. Connect the extension tubes to the diverter valve. Make sure the arrow on the valve is positioned as shown and the diverter Extension tube valve is connected as shown. Fig. 9 NOTE 1: Tubes and diverter valve are NOT INCLUDED. Diverter NOTE 2: Use diverter valve to simultaneously run a valve...
- Page 5 12. Place the filter assembly in the water. Fig. 12 Fig. 12 CARE AND MAINTENANCE • Occasional cleaning of the filter pads will be necessary to ensure the proper functioning of the system. The coarse filter pad is a designed to trap large debris. The fine filter pad catches smaller particles.
- Page 6 All aquanique™ electrical products are warranted to the user against defective material and workmanship, under normal working conditions for 1 year from the date of purchase. All aquanique™ liners are warranted to the user against defective workmanship, under normal working conditions for 20 years from the date of purchase.
