Hold the tool in both hands and adopt a stable
stance that gives a good view of the work while
keeping you clear of the bit.
Do not work in areas where you are forced
to stand on loose debris or on a slippery
uneven surface.
If possible, drape the tool' s flex over one shoulder to
keep it clear of the bit, but make sure there is still
enough slack so you are not restricted in movement.
Start drilling slowly and carefully, then, once the hole
is established, concentrate on drilling in a straight
line – with the drill at right angles to the surface,
where appropriate.
Apply just enough pressure to achieve a steady
rate of penetration – too much or too little pressure
will overheat and/or blunt the drill bit and could damage
the electric motor.
When drilling into hard material such as masonry,
withdraw the bit from time to time, keeping the drill
running, in order to cool the bit and the drill' s motor.
This will also clear waste from the hole.
When drilling large diameter holes with TCT or HSS twist
bits, drill a small pilot hole first, then drill again with a
larger bit, until the correct size is achieved.
If using a flat blade for timber, do not use a pilot as the
flat bit relies on its own pilot tip to keep the blade central.
If you wish to use the drill as an electric screwdriver,
use an adaptor to hold the various driver tips. But
be warned, some models don't have reverse so once the
screw is in place you may have to remove it manually!.
EQUIPMENT CARE
Never push the drill beyond its natural capabilities.
If it won't do the job you want with reasonable ease,
change it for a more powerful model.
Never let the drill bit or motor over-heat. Stop
work at frequent intervals and run the drill for a
minute or so, just holding it in your hands. The air
drawn in and around it will cool everything down and
prevent damage.
Regularly check that the air vents in the drill body
are clear. If these become blocked with dust, clean them
out using a soft brush before continuing, taking care not
to push dirt into the drill body.
Avoid over-tightening the drill chuck when securing
a bit, and never attempt to fit a bit, larger than the
recommended chuck capacity.
When not in use, store the equipment somewhere
clean, dry and safe from thieves.
FINISHING OFF
Remove all drill bits and clean up the drill ready
for return.
Check that the drill still has its chuck key, neatly
coil the flex and place in the carrying case ready
for return to your local HSS Hire Shop.
Contact your local
0990 282828
©HSS Hire Service Group Plc 1997 No. 523/01
Group Office: 25 Willow Lane, Mitcham, Surrey CR4 4TS
Operating & Safety Guide 523
Hire Shops
Two Speed
Percussion Drill
General-purpose drill suitable for
drilling into all types of masonry,
metal and timber and for most DIY
jobs around the house.
Code 01112
