marks on door and firmly press gasket into place.
(If the original adhesive no longer holds the gasket
USER GUIDE
in place, it may be necessary to apply a strip of
two-sided tape.)
Install top hinge and door:
Top Hinge
Left Side
1. Remove pivot screw from hinge, flip hinge over, and
install the pivot screw in the same hole from the
opposite surface.
2. Lift the door onto the bottom hinge.
3. Align edge of the hinge with the outer edge of the unit.
4. Tighten three screws and replace hinge cover.
Align and adjust the door:
Align and adjust the door (see DOOR ALIGNMENT AND
ADJUSTMENT)
Install grille
Door Adjustments
Top Hinge
Right Side
Pivot
Screw
