Removing the HDD Fan

1. See "Removing the Bezel Door" on page 31.
2. See "Removing the Left Side Panel" on page 34.
3. See "Removing the Front Bezel" on page 36.
4. See "Removing the Card Reader Drive" on page 42.
5. Disconnect the fan cable from the mainboard.
6. Remove the four screws (H) that secure the fan to the chassis.
Screw (Quantity)
M#6-32 L20 BZN (4)
7. Remove the fan from the chassis.
56
Color
Black
Torque
N/A 86.00J10.A60
Part No.
Chapter 3
