Removing the Fan from the Liquid Cooler

1. See "Removing the Bezel Door" on page 31.
2. See "Removing the Left Side Panel" on page 34.
3. See "Removing the Liquid Cooler Fan Assembly" on page 49.
4. Remove the four screws (F) that secure the fan to the heat exchanger on the liquid cooler fan assembly
and store screws and washer for later use, then detach the fan from the cooler.
Screw (Quantity)
Liquid cooler fan screw (4)
Chapter 3
Color
Silver 4.5 to 5.5 kgf-cm
Torque Part No.
N/A
