Removing the USB3.0 Card
Disconnect the power cable from the USB3.0 card.
1.
Remove the screw that secures the card to the chassis.
2.
Gently pull the card to remove it from the mainboard.
3.
Note:
Circuit boards >10 cm² has been highlighted with the yellow rectangle as above image shows. Please
detach the Circuit boards and follow local regulations for disposal.
Chapter 3
33
