Remove the screw that secures the card to the chassis.
3.
Firstly release the retention latch(1) downward to unlock the card, then gently pull the card to remove it
4.
from the mainboard.
Note:
Circuit boards >10 cm² has been highlighted with the yellow rectangle as above image shows. Please
detach the Circuit boards and follow local regulations for disposal.
32
Chapter 3
