- Page 1 INDUSTRIAL AIR DIE GRINDER STRAIGHT INDUSTRIAL AIR DIE GRINDER 1492NM STRAIGHT TORQUE UNIQUE ADJUSTABLE SPEED YEAR TWIN BEARING SYSTEM REGULATOR WARRANTY CONSUMPTION K13230 ED1 December 15...
- Page 2 5. ¼” Collet size 6. Speed Selector 7. Spindle Wrench 8. Collet Wrench 9. Nitto Style Fitting Model No: ........................K13230 Description: ......................Industrial Air Die Grinder Straight Free Speed:........................ 22,000RPM Collet Size: ......................¼” Air Inlet: ........................¼” Avg Air Consumption: ..................
- Page 3 INDUSTRIAL AIR DIE GRINDER STRAIGHT General Safety Warnings Save all warnings and instructions for future reference. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. 1) Work Area a.
- Page 4 INDUSTRIAL AIR DIE GRINDER STRAIGHT 4) Service a. Tool service must be performed only by qualified repair personnel. b. When servicing a tool, use only identical replacement parts. Use only authorized parts. c. Use only the lubricants specified by the manufacturer. 5) Additional Safety Warnings a.
- Page 5 INDUSTRIAL AIR DIE GRINDER STRAIGHT 7) Additional Safety Instructions For Die Grinders a. Use only burr or stone types that are recommended for your air tool. b. Make sure the burr or stone is not contacting the work piece before the tool is turned on. Having the burr/stone resting on the work piece before starting the tool could result in the tool kicking as it grips the work piece, this could cause potential personal harm and/or material damage.
- Page 6 INDUSTRIAL AIR DIE GRINDER STRAIGHT 9) Operation Screw in Nitto Style Fitting (9) to the air inlet (1). Thread (teflon) tape may be required to ensure a leak free seal. Adjust thje ultimate speed of the Die grinder by turning the speed selector (6) left or right, using a flat blade screw driver (screw driver not included).
- Page 7 CONE MUFFLER K13230-7 VALVE STEM K13230-23 BEARING SPACER K13230-8 O-RING(3.5*1.4) K13230-24 FRONT PLATE K13230-9 AIR INLET K13230-25 BEARING(608ZZ) K13230-10 EXHAUST SLEEVE K13230-26 WASHER K13230-11 O-RING(26.7*1.78) K13230-27 CLAMP NUT K13230-12 SPRING PIN K13230-28 SPINDLE K13230-13 LEVER K13230-29 COLLET K13230-14 PROTECTING RUBBER...
- Page 8 www.kincrome.com.au...
