Flotec 4202A Series Owner's Manual

Flotec 4202A Series Owner's Manual

Submersible solids handling pumps
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

P.O. Box 342, Delavan, WI 53115
Phone: 1-800-365-6832
Fax: 1-800-526-3757
E-Mail: flotec@flotecpump.com
Web Site: http://www.flotecwater.com
Installation/Operation/Parts
For further operating, installation,
or maintenance assistance:
Call 1-262-728-5551
English
. . . . . . . . . . . . . .
©2000, PRINTED IN U.S.A.
®
4202A SERIES
Installation/Fonctionnement/Pièces
Pour plus de renseignements
concernant l'utilisation,
l'installation ou l'entretien,
Composer le 1 (262) 728-5551
Pages 2-7
Français
OWNER'S MANUAL
Submersible Solids
Handling Pumps
NOTICE D'UTILISATION
Pompes submersibles
pour les matières solides
MANUAL DEL USUARIO
Bombas sumergibles para el
manejo de líquidos con sólidos
3292 0798 ASB
Pages 8-13
. . . . . . . . . . .
Instalación/Operación/Piezas
Para mayor información sobre el
funcionamiento, instalación o
mantenimiento de la bomba:
Llame al 1-262-728-5551
Español
Paginas 14-19
. . . . . . . . . .
FPX265 (3/2/00)
