Operating Instructions
Air Conditioner
Model No.
Indoor Unit
CS-U71XKR
CS-U80XKR
Outdoor Unit
CU-U71XKR
CU-U80XKR
Operating Instructions
Air Conditioner
Before operating the unit, please read these operating
instructions thoroughly and keep them for future reference.
Before installation, the installer should:
Read the Installation Instructions, then request the customer
keep them for future reference.
Remove the remote control packed with the indoor unit.
ACXF55-31120
Advertisement
Related Manuals for Panasonic CS-U71XKR
Summary of Contents for Panasonic CS-U71XKR
- Page 1 Operating Instructions Air Conditioner Model No. Indoor Unit Outdoor Unit CS-U71XKR CU-U71XKR CS-U80XKR CU-U80XKR Operating Instructions Air Conditioner Before operating the unit, please read these operating instructions thoroughly and keep them for future reference. Before installation, the installer should: Read the Installation Instructions, then request the customer keep them for future reference.
- Page 2 Provides maximum comfort with optimal energy saving methods. Use the remote control within 8 m from the remote control receiver on the indoor unit. Quick Guide Inserting the batteries Clock setting 1 Press , then press to set the time. 1 Pull out the back cover of remote control.
-
Page 3: Table Of Contents
Thank you for purchasing Panasonic Air Conditioner. Table of Contents Safety Precautions …… 4-11 How to Use …………………12-13 To Learn More... ………… 14 Cleaning the Air Conditioner ……………… 15 Troubleshooting ………… 16-18 Information………………… 19 Accessories • Remote control • AAA or R03 batteries × 2 •... -
Page 4: Safety Precautions
Safety Precautions To prevent personal injury, injury to others or property damage, please comply with the following: WARNING Incorrect operation due to failure to follow instructions below may cause harm or damage, the seriousness of which is classifi ed as below: This appliances is not intended for accessibility by the Indoor unit and outdoor unit general public. - Page 5 Power supply CAUTION Do not use a modifi ed cord, joint cord, extension cord or unspecifi ed cord to prevent Indoor unit and outdoor unit overheating and fi re. To prevent overheating, fi re or electric shock: Do not wash the indoor unit with water, •...
- Page 6 Safety Precautions Must always ensure that foreign matter (oil, WARNING water, etc.) does not enter the piping. Also, when storing the piping, securely seal the opening by pinching, taping, etc. (Handling of R32 is similar to R410A.) This appliance is fi lled with R32 •...
- Page 7 f) Precautions shall be taken to avoid 2. Servicing excessive vibration or pulsation to 2-1. Service personnel refrigerating piping. • The system is inspected, regularly supervised g) Ensure protection devices, refrigerating and maintained by a trained and certifi ed piping and fittings are well protected service personnel who is employed by the against adverse environmental effects person user or party responsible.
- Page 8 Safety Precautions 2-3. Checking for presence of refrigerant 2-7. Checks to the refrigerating equipment • The area shall be checked with an • Where electrical components are being appropriate refrigerant detector prior to and changed, they shall be fi t for the purpose and during work, to ensure the technician is aware to the correct specifi...
- Page 9 3. Repairs to sealed components 6. Detection of fl ammable refrigerants • During repairs to sealed components, all • Under no circumstances shall potential electrical supplies shall be disconnected from sources of ignition be used in the searching or the equipment being worked upon prior to any detection of refrigerant leaks.
- Page 10 Safety Precautions 8. Removal and evacuation 9. Charging procedures • When breaking into the refrigerant circuit • In addition to conventional charging to make repairs – or for any other purpose procedures, the following requirements shall – conventional procedures shall be used. be followed.
- Page 11 e) If a vacuum is not possible, make a manifold • The recovery equipment shall be in good so that refrigerant can be removed from working order with a set of instructions various parts of the system. concerning the equipment that is at hand and f) Make sure that cylinder is situated on the shall be suitable for the recovery of fl...
-
Page 12: How To Use
How to Use To adjust airfl ow direction Upper direction AIR SWING Indicators Lateral direction POWER TIMER • Do not adjust the fl ap by hand. * For details operation, refer “To Learn More..” To adjust FAN SPEED and QUIET condition FAN SPEED/ QUIET FAN SPEED:... - Page 13 See "To Learn More..." for details. To maximise comfort while sleeping SLEEP • This operation provides you with a comfortable environment while sleeping. It will automatically adjust the sleep pattern temperature during the activation period. • The indoor unit indicator will dim when this operation is activated. This is not applicable if the indicator brightness has been manually dimmed.
-
Page 14: To Learn More
To Learn More... Operation mode AUTO : The POWER indicator blinks at the initial stage. COOL : Provides effi cient comfort cooling to suit your needs. : Operates at low fan speed for a gentle cooling operation. : To circulate air in the room. Energy saving temperature setting You may save energy when operating the unit within the recommended temperature range. -
Page 15: Cleaning The Air Conditioner
Cleaning the Air Conditioner Cleaning has to be carried out at regular Indoor unit intervals to ensure the unit is at optimal ( Structure of the unit may vary depending performance. A dirty unit may cause on the model) malfunction and you may retrieve “H 99” Front panel Aluminium fi... -
Page 16: Troubleshooting
Troubleshooting The following symptoms do not indicate malfunction. Symptom Cause POWER indicator blinks before the unit is • This is the preliminary step to prepare for the TIMER switched on. operation after it has been set. • When Timer is set ON, the unit may start earlier (up to 15 minutes) before the actual set time to achieve the desired temperature on time. - Page 17 When... ■The remote control is missing or a malfunction has occurred 1. Raise the front panel. 2. Press AUTO OFF/ON once to use in AUTO mode. 3. Press AUTO OFF/ON until you hear 1 beep, then release to use in forced COOL mode.
- Page 18 Troubleshooting How to retrieve error codes If the unit stops and the TIMER indicator blinks, use the remote control to retrieve the error code. Press until you hear beep Press for sound, then write down the 5 seconds error code TIMER TIMER CANCEL...
-
Page 19: Information
Information Information for Users on Collection and Disposal of Old Equipment and used Batteries [Information on Disposal in other Countries outside the European Union] These symbols are only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal. - Page 20 Panasonic Corporation 1006 Kadoma, Kadoma City, Osaka, Japan Website: http://www.panasonic.com © Panasonic Corporation 2021 ACXF55-31120 Printed in Malaysia SS0721-0...
