PARTNAME
LOWER CASE
(TravelMate 6460 only)
UPPER CASE W/O
FINGER PRINTER
(TravelMate 6460 only)
UPPER CASE WITH
FINGER PRINTER
(TravelMate 6460 only)
MIDDLE COVER
(TravelMate 6460 only)
CONNECTOR 2ND HDD
BRACKET 2ND HDD
UPPER CASE 2ND HDD
LOWER CASE 2ND HDD
COMBO BEZEL GBASE
SUPER MULTI BEZEL
GBASE
OPTICAL RAIL HOLDER
HDD HOLDER
CPU HEATSINK FINGER
VGA HEATSINK FINGER
DESCRIPTON
"FRU,BOTTOM CASE
ASSEMBLY"
"FRU,TOP CASE
ASSEMBLY"
"FRU,TOP CASE
ASSEMBLY"
"SET,COVER,SWITCH"
"E.SET,FPC+CONN,50P/
20P,38.06MM"
"BRACKET,HDD,BOTTOM
,SECC"
"CASE,HDD,BOTTOM,PC
+ABS"
"CASE,HDD,TOP,PC+AB
S"
"SET,BEZEL,ODD"
"SET,BEZEL,ODD"
"HOLDER,ODD,PC+ABS"
"FRAME,HDD,AL"
"FINGER,CPU,SUS301"
"FINGER,VGA,SUS301"
ACER PART NO.
60.TEDVN.001
60.TEDVN.002
60.TEDVN.012
60.TEDVN.003
22.D03VN.001
33.D03VN.002
60.D03VN.003
60.D03VN.004
42.TCXVN.005
42.TCXVN.007
42.TCXVN.006
42.TCXVN.008
33.TCXVN.001
33.TCXVN.002
