# Name
15 D719
17 JACK703
19 CN717
21 CN715
23 CN706
25 CN710
Note: CN6002 (S-video port) and CN6001 (Modem jack) locate on IO board which is the apposite direction
from the bottom view.
97
Description
IR receiver
Line-in jack
HDD connector
RTC battery connector
PCI-E socket
DIMM socket
# Name
16 JACK704 Microphone jack
18 JACK702 Headphones/speaker/line-
out jack
20 CN714 Battery connector
22 CN509 ODD connector
24 U708 South bridge
26 CN711 DIMM socket
Description
