Jumper And Connector Location; Top View - Acer TravelMate 6460 Service Manual

Hide thumbs Also See for TravelMate 6460:
Table of Contents

Advertisement

Jumper and Connector Location

Top view

#
Name
1
CN3
3
CN1
5
CN6
Chapter 5
Description
LCD cable connector
RJ11 connector
Keyboard connector
#
Name
2
CN4
Modem board connector
4
CN5
Launch board connector
6
CN7
Acer FineTrack connector
Chapter 5
Description
94
