DOREL ASIA

Model No:

COUNTER HEIGHT

WM3514

DESK

UPC CODE:

0-65857-15762-8

NOTE:

THIS INSTRUCTION BOOKLET

IMPORTANT

CONTAINS

SAFETY

INFORMATION. PLEASE READ

AND KEEP FOR FUTURE

REFERENCE.

Lot number:

(TAKEN FROM CARTON)

___________________

Date of purchase:

_______ / _______ / _______

DO NOT RETURN PRODUCT TO THE STORE.

If a part is missing or damaged, contact our customer

service department. We will replace the

part FREE of charge.

NEED HELP!

CALL US FOR AS

Tel #: 1-800-295-1980

E-Mail: das@dorel.com

1-800-295-1980

Fax #: 514-353-7819

DO NOT RETURN

E-MAIL:DAS@DO

Need help?

Do you have a question about the WM3514 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dorel Asia WM3514

Page 1 DOREL ASIA Model No: COUNTER HEIGHT WM3514 DESK UPC CODE: 0-65857-15762-8 NOTE: THIS INSTRUCTION BOOKLET IMPORTANT CONTAINS SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) ___________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
Page 2: Care And Cleaning
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase.
Page 3 COUNTER HEIGHT DESK WM3514 HARDWARE LIST Ø5/32'' x 1'' Ø5/32'' x 3/4'' FLAT HEAD SCREW ROUND HEAD BOLT KNOB 16 PCS 2 PCS 2 PCS Ø3 x 12 MM Ø1/4'' x 3'' FLAT HEAD SCREW HEX SOCKET HEAD BOLT BARREL NUT...
Page 4: Parts List
COUNTER HEIGHT DESK WM3514 PARTS LIST DRAWER FRONT DRAWER SIDE 2 PCS 4 PCS DRAWER BOTTOM DRAWER BACK 2 PCS 2 PCS TOP PANEL SUPPORT RAIL 1 PC 1 PC RIGHT SIDE PANEL RAIL 1 PC 3 PCS...
Page 5 COUNTER HEIGHT DESK WM3514 PARTS LIST RAIL BACK PANEL UPPER RAIL 3 PCS 1 PC BACK PANEL LOWER RAIL DRAWER MIDDLE RAIL 1 PC 1 PC SHELF BACK PANEL 2 PCS 1 PC DIVIDER PANEL SMALL TOP PANEL 1 PC...
Page 6 COUNTER HEIGHT DESK WM3514 PARTS LIST LEFT LOWER RAIL LEFT BACK UPPER RAIL 1 PC 1 PC LEFT FRONT UPPER RAIL LEFT CENTER RAIL 1 PC 1 PC LEFT SHELF LEFT SIDE PANEL 1 PC 1 PC DIVIDER ADJUSTABLE SHELF...
Page 7 COUNTER HEIGHT DESK WM3514 STEP 1 Attach drawer sides (B) to drawer front (A) with flat head screws (1). Slide drawer bottom (C) into the grooves of the drawer sides (B) and drawer front (A). Attach drawer back (D) to drawer sides (B) with flat head screws (1).
Page 8 COUNTER HEIGHT DESK WM3514 STEP 2 Attach support rail (F) to the top panel (E) with flat head screws (4). Use a Phillips head screw driver (not included) to tighten the screws.
Page 9 COUNTER HEIGHT DESK WM3514 STEP 3 Insert wood dowels (7) into right side panel (G) as shown below. Insert barrel nuts (6) into rails (H & I), back panel upper rail (J) and back panel lower rail (K) as shown below.
Page 10 COUNTER HEIGHT DESK WM3514 STEP 4 Insert one shelf (M) into the grooves of rails (H) as shown below. Insert another shelf (M) into the grooves of rail (H) and back panel upper rail (J) as shown below. Insert the back panel (N) into the grooves of back panel upper rail (J) and back panel lower rail...
Page 11 COUNTER HEIGHT DESK WM3514 STEP 5 Insert wood dowels (7) and barrel nuts (6) into rails (H & I), back panel upper rail (J), back panel lower rail (K) and drawer middle rail (L) as shown below. Attach divider panel (O) to the assembled unit with hex socket head bolts (5) as shown below.
Page 12 COUNTER HEIGHT DESK WM3514 STEP 6 Insert cam bolts (8) into the correct hole of left back upper rail (R) and left front upper rail (S) as shown below. Insert cam locks (9) and wood dowels (7) into the correct hole of left center rail (T) as shown below.
Page 13 COUNTER HEIGHT DESK WM3514 STEP 7 Insert left shelf (U) into the grooves of left back upper rail (R) and left front upper rail (S).
Page 14 COUNTER HEIGHT DESK WM3514 STEP 8 Insert wood dowels (7) and barrel nuts (6) into the correct hole of left back upper rail (R), left front upper rail (S) and left lower rail (Q). Attach left side panel (V) to the assembled unit with hex socket head bolts (5).
Page 15 COUNTER HEIGHT DESK WM3514 STEP 9 Insert cam bolts (8) into the correct hole of small top panel (P). Insert cam locks (9) into the correct hole of right side panel (G) and divider panel (O). Fasten small top panel (P) to right side panel (G) and divider panel (O) by rotating cam locks (9) 1/2 turn clockwise.
Page 16 COUNTER HEIGHT DESK WM3514 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. 15 lbs That's it ! You've finished assembling your counter height desk .
Page 17 MODEL #: WM3514 A B B A B B A B B Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S).
