8. Carefully pry open the LCD bezel and remove the bezel from the LCD module.
NOTE: The bottom side of the bezel is glued to the lcd panel, be careful when trying to remove the bezel.

Removing the LCD module with the Brackets

1. See "Removing the Battery Pack" on page 62.
2. See "Removing the Lower Cover" on page 64.
3. See "Removing the WLAN Board Modules" on page 68.
4. See "Removing the Middle Cover and the Power Board" on page 78.
5. See "Removing the LCD Module" on page 81.
6. See "Removing the LCD Bezel" on page 97.
7. Disconnect the cable from the camera board.
98 Chapter 3
