3. Insert the USB HDD and reboot computer.
ease restart the system.
C:\P5LM0100\flash
Figure 2-13. DOS Flash
4. Flash is complete when the message, Flash Programming Complete is shown.
System will restart automatically when finished.
NOTE:
NOTE:
If AC power is not connected, the following message is shown (Figure 2-14).
Plug in the AC power to continue.
Figure 2-14. AC Power Warning
System Utilities
Please do not remove the AC power!
Insyde Flash Utility for InsydeH20
Initializing
File loading 100 %
Current BIOS Model name : NELA0
New BIOS Model name : NELA0
Current BIOS version: V0.12
New BIOS version: V0.12
Updating Block at FFFE8000
Warning: No AC power connect
Version 1.3v
2-15
